Dayton Audio Pro 15 in. 8 Ohm Neodymium Midbass Woofer Odeum 15N

2 Questions, 2 Answers or
Dayton Audio
Part #295-643

Dayton Audio Pro 15 in. 8 Ohm Neodymium Midbass Woofer Odeum 15N

Dayton Audio
Part #295-643
Model: 15MB500N-8
2 Questions, 2 Answers or
Live sound is back in business! Dayton Audio wants you to hit the road with confidence and maximize your profitability at your next gig. Dayton Audio is a worldwide leader in raw frame drivers. We are passionate audio enthusiasts with a vision to offer the best performance to price value in the industry. After extensive market research, vendor evaluation, and sample driver testing, we are proud to introduce to you the Dayton Audio ODEUM Series.
Key Features
  • Powerful neodymium motor for superior output.
  • Copper inductance cap for low distortion
  • Paper cone and cloth m-roll surround for high clarity, smooth response, and linear excursion for pounds of punch
  • 3” Inside/outside wound copper voice coil leads on fiberglass former lends solid power handling capability
  • Under spider and rear periphery venting allow for a cooler running voice coil
  • Low Qts means high damping and smaller boxes
  • With a Dayton Audio 5 year warranty, it’s more than a guarantee, it’s a promise. We stand behind our products and our warranty is a demonstration of our commitment to quality and reliability.
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $152.98
+ FREE SHIPPING
MSRP: $289.99
Save $137.01 (47%)
Bulk Pricing
Quantity:Qty: 1-3 $152.98/ea
Quantity:Qty: 4+$149.98/ea
Ships next business day. Details

148In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio Pro 15 in. 8 Ohm Neodymium Midbass Woofer Odeum 15N

Dayton Audio Pro 15 in. 8 Ohm Neodymium Midbass Woofer Odeum 15N

ode· um | \ ō-ˈdē-əm: An ancient Greek and Roman concert hall used for music and poetry.

Using the knowledge from decades of driver design and engineering, Dayton Audio is placing an emphasis on technical excellence, product reliability, and innovation with the Odeum Series of speaker components! The Odeum Series takes the stage with a new line of professional drivers made for any venue.

Key Specs:

  • Nominal Diameter: 15"
  • Power Handling (RMS): 500 Watts
  • Power Handling (MAX): 1000 Watts
  • Impedance: 8 Ω
  • Frequency Response: 40Hz - 4.5kHz
  • Sensitivity: 98.6 dB 2.83V/1m
  • Voice Coil Diameter: 3"
  • Maximum Linear Excursion: 6.55mm

    Frequency Response & Impedance

    The Dayton Audio Pro 15 has a response that matches a large number of horn drivers and tweeters due to its high efficiency in the frequency range of human voices and midrange detail of stringed instruments. The impedance curve of the Apollo 15 makes it easy to pair up with your favorite compression driver without taxing your power amplifiers!

    Dayton Audio Pro 15

    The Dayton Audio Pro 15 is a 15" mid-bass woofer that is guaranteed to outperform the stock woofers in your PA system. A 500W power limit is achieved through the combination of a neodymium motor, a 3" voice coil with a fiberglass former, and a copper inductance cap to lower distortion. A paper cone with cloth M-roll surrounds provides a neutral tone that is easy to tune, and peripheral venting helps keep the whole system cool when playing!

    A solution for every need

    We feel we have hit the sweet spot in price and specs in the pro audio market with this workhorse line of subwoofers, midrange, and high-frequency drivers. The ODEUM series consist of two 1200W 18” subwoofers (one neodymium, one ceramic), 5 sizes and various power ratings of neodymium mid-bass, and two 1” exit compression drivers (one bolt-on, one screw-on). Upgrade, replace, or create a new pro sound system with the ODEUM series.

    We've Got Your Back

    We stand behind our products and our warranty is a demonstration of our commitment to quality and reliability.

    Learn More

    Shop the Whole Odeum Series

    Dayton Audio Pro 6

    Nominal Diameter: 6.5"
    Frequency Response: 90Hz - 8.0kHz
    Shop Now

    Dayton Audio Pro 8

    Nominal Diameter: 8"
      Frequency Response: 75Hz - 5.8kHz

      Dayton Audio Pro 10

      Nominal Diameter: 10"
      Frequency Response: 60Hz - 4.2kHz

      Dayton Audio Pro 12

      Nominal Diameter: 12"
      Frequency Response: 40Hz - 5.6kHz

      Dayton Audio Pro 18F

      Nominal Diameter: 18"
      Frequency Response: 35Hz - 1.0kHz

      Dayton Audio Pro 18

      Nominal Diameter: 18"
      Frequency Response: 35Hz - 1.0kHz

      Ryman 1017S

      Exit Diameter: 1"
      Frequency Response: 1kHz - 20kHz

      Ryman 1017B

      Exit Diameter: 1"
      Frequency Response: 1kHz - 20kHz
      Shop The Whole Odeum Line
      Learn More
      Request Quote

      Product Details

      BrandDayton Audio
      Model15MB500N-8
      Part Number295-643
      UPC848791008511
      Unit of MeasureEach
      Weight14

      Product Specifications

      Nominal Diameter15"
      Power Handling (RMS)500 Watts
      Power Handling (MAX)1000 Watts
      Impedance8Ω
      Frequency Response40 to 4,500Hz
      Sensitivity98.6dB 2.83V/1m
      Voice Coil Diameter3"

      Thiele-Small Parameters

      Resonant Frequency (Fs)44Hz
      DC Resistance (Re)5.8Ω
      Voice Coil Inductance (Le)0.14mH
      Mechanical Q (Qms)10.47
      Electromagnetic Q (Qes)0.34
      Total Q (Qts)0.33
      Compliance Equivalent Volume (Vas)5.46ft³
      Mechanical Compliance of Suspension (Cms)0.142mm/N
      BL Product (BL)20.96T·m
      Diaphragm Mass Inc. Airload (Mms)93.39g
      Maximum Linear Excursion (Xmax)6.55mm
      Surface Area of Cone (Sd)844.53cm²

      Materials of Construction

      Cone MaterialCoated Paper
      Surround MaterialPaper
      Voice Coil Wire MaterialCopper
      Voice Coil FormerFiberglass
      Basket / Frame MaterialSteel
      Magnet MaterialNeodymium

      Mounting Information

      Overall Outside Diameter15.42"
      Baffle Cutout Diameter13.89"
      Depth6.65"
      # Mounting Holes8

      Parts Express Staff Recommended Enclosure Volume

      Sealed Volume1.7ft³
      Sealed F3114Hz
      Vented Volume3.5ft³
      Vented F349Hz
