  • Dayton Audio Pro 6.5 in. 8 Ohm Neodymium Midbass Woofer Odeum 6.5N

CLEARANCE Dayton Audio Pro 6.5 in. 8 Ohm Neodymium Midbass Woofer Odeum 6.5N

20 Questions, 41 Answers or
Dayton Audio
Part #295-638

CLEARANCE Dayton Audio Pro 6.5 in. 8 Ohm Neodymium Midbass Woofer Odeum 6.5N

Dayton Audio
Part #295-638
Model: 6MB200N-8
20 Questions, 41 Answers or
Live sound is back in business! Dayton Audio wants you to hit the road with confidence and maximize your profitability at your next gig. Dayton Audio is a worldwide leader in raw frame drivers. We are passionate audio enthusiasts with a vision to offer the best performance to price value in the industry. After extensive market research, vendor evaluation, and sample driver testing, we are proud to introduce to you the Dayton Audio ODEUM Series.
Key Features
  • Powerful neodymium motor for superior output.
  • Copper inductance cap for low distortion
  • Paper cone and cloth m-roll surround for high clarity, smooth response, and linear excursion for pounds of punch
  • 2” Inside/outside wound copper voice coil leads on fiberglass former lends solid power handling capability
  • Under spider and rear periphery venting allow for a cooler running voice coil
  • Low Qts means high damping and smaller boxes
  • With a Dayton Audio 5 year warranty, it’s more than a guarantee, it’s a promise
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
CLEARANCE $59.98
MSRP: $159.99
Save $100.01 (63%)
Bulk Pricing
Order in the next 2 hr 46 min to ship today. Details

231In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio Pro 6.5 in. 8 Ohm Neodymium Midbass Woofer Odeum 6.5N

Dayton Audio Pro 6.5 in. 8 Ohm Neodymium Midbass Woofer Odeum 6.5N

ode· um | \ ō-ˈdē-əm: An ancient Greek and Roman concert hall used for music and poetry.

Using the knowledge from decades of driver design and engineering, Dayton Audio is placing an emphasis on technical excellence, product reliability, and innovation with the Odeum Series of speaker components! The Odeum Series takes the stage with a new line of professional drivers made for any venue.

Key Specs:

  • Nominal Diameter: 6-1/2"
  • Power Handling (RMS): 200 Watts
  • Power Handling (MAX): 400 Watts
  • Impedance: 8 Ω
  • Frequency Response: 90Hz - 8kHz
  • Sensitivity: 94.4 dB 2.83V/1m
  • Voice Coil Diameter: 2"
  • Maximum Linear Excursion: 3.7mm

Frequency Response & Impedance

The Dayton Audio Apollo 6 has a response that matches a large number of horn drivers due to its high efficiency in the frequency range of human voices and midrange detail of stringed instruments. The impedance curve of the Apollo 6 makes it easy to pair up with your favorite tweeters without taxing your power amplifiers!

Dayton Audio Pro 6

The Dayton Audio Pro 6 is a 6.5" mid-bass woofer that is guaranteed to outperform the stock woofers in your PA system. A 200W power limit is achieved through the combination of a neodymium motor, a 2" voice coil with a fiberglass former, and a copper inductance cap to lower distortion. A paper cone with cloth M-roll surrounds provides a neutral tone that is easy to tune, and peripheral venting helps keep the whole system cool when playing!

A solution for every need

We feel we have hit the sweet spot in price and specs in the pro audio market with this workhorse line of subwoofers, midrange, and high-frequency drivers. The ODEUM series consist of two 1200W 18” subwoofers (one neodymium, one ceramic), 5 sizes and various power ratings of neodymium mid-bass, and two 1” exit compression drivers (one bolt-on, one screw-on). Upgrade, replace, or create a new pro sound system with the ODEUM series.

We've Got Your Back

We stand behind our products and our warranty is a demonstration of our commitment to quality and reliability.

Learn More

Shop the Whole Odeum Series

Dayton Audio Pro 8

Nominal Diameter: 8"

Frequency Response: 75Hz - 5.8kHz

Shop Now

Dayton Audio Pro 10

Nominal Diameter: 10"

Frequency Response: 60Hz - 4.2kHz

Shop Now

Dayton Audio Pro 12

Nominal Diameter: 12"

Frequency Response: 40Hz - 5.6kHz

Shop Now

Dayton Audio Pro 15

Nominal Diameter: 15"

Frequency Response: 40Hz - 4.5kHz

Shop Now

Dayton Audio Pro 18F

Nominal Diameter: 18"

Frequency Response: 35Hz - 1.0kHz

Shop Now

Dayton Audio Pro 18

Nominal Diameter: 18"

Frequency Response: 35Hz - 1.0kHz

Shop Now

Ryman 1017S

Exit Diameter: 1"

Frequency Response: 1kHz - 20kHz

Shop Now

Ryman 1017B

Exit Diameter: 1"

Frequency Response: 1kHz - 20kHz

Shop Now
Shop The Whole Odeum Line
Learn More
Request Quote

Product Details

BrandDayton Audio
Model6MB200N-8
Part Number295-638
UPC848791008467
Unit of MeasureEach
Weight4.8

Product Specifications

Nominal Diameter6-1/2"
Power Handling (RMS)200 Watts
Power Handling (MAX)400 Watts
Impedance8Ω
Frequency Response90 to 8,000Hz
Sensitivity94.4dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)102.8Hz
DC Resistance (Re)6.06Ω
Voice Coil Inductance (Le)1.29mH
Mechanical Q (Qms)8.02
Electromagnetic Q (Qes)0.29
Total Q (Qts)0.28
Compliance Equivalent Volume (Vas)0.12ft³
Mechanical Compliance of Suspension (Cms)0.141mm/N
BL Product (BL)14.94T·m
Diaphragm Mass Inc. Airload (Mms)16.92g
Maximum Linear Excursion (Xmax)3.77mm
Surface Area of Cone (Sd)132.67cm²

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialPaper
Voice Coil FormerFiberglass
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.59"
Baffle Cutout Diameter5.75"
Depth3.13"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.18ft³
Sealed F3103Hz
Vented Volume0.25ft³
Vented F384Hz
