  • Dayton Audio DC130A-8 5-1/4" Classic Woofer Speaker

Dayton Audio DC130A-8 5-1/4" Classic Woofer Speaker

Dayton Audio
Part #295-303

Dayton Audio DC130A-8 5-1/4" Classic Woofer Speaker

Dayton Audio
Part #295-303
Model: DC130A-8
The Dayton Audio DC130A-8 is a compact and inexpensive unshielded variant of the popular DC130AS-8 magnetically shielded woofer.
Key Features
  • Pincushion steel frame for great looks and strength
  • Coated paper cone provides smooth response and reduced cone breakup
  • Aluminum voice coil former for high power handling
  • Large diameter flat spider and good Xmax for clean bass
  • Suitable for sealed or vented enclosures
Your Price: $24.98
MSRP: $31.99
Save $7.01 (22%)
Bulk Pricing
Quantity:Qty: 1-3 $24.98/ea
Quantity:Qty: 4+$22.48/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio DC130A-8 5-1/4" Classic Woofer Speaker

One of the main design goals at Dayton Audio is to create loudspeakers that can achieve high levels of performance at reasonable prices. The Dayton Audio DC130A-8 5-1/4" woofer is a great example of this approach. It features a non-pressed treated paper cone, rubber half-roll surround, ASV voice coil, coated cloth dust cap, and excellent low frequency response.

Product Details

BrandDayton Audio
ModelDC130A-8
Part Number295-303
UPC844632093968
Unit of MeasureEach
Weight2

Product Specifications

Nominal Diameter5-1/4"
Power Handling (RMS)40 Watts
Power Handling (MAX)60 Watts
Impedance8Ω
Frequency Response50 to 5,000Hz
Sensitivity88.7dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)53.2Hz
DC Resistance (Re)5.7Ω
Voice Coil Inductance (Le)0.75mH
Mechanical Q (Qms)1.9
Electromagnetic Q (Qes)0.51
Total Q (Qts)0.41
Compliance Equivalent Volume (Vas)0.49ft³
Mechanical Compliance of Suspension (Cms)0.96mm/N
BL Product (BL)5.88T·m
Diaphragm Mass Inc. Airload (Mms)9.3g
Maximum Linear Excursion (Xmax)2.5mm
Surface Area of Cone (Sd)91.6cm²

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter5.28"
Baffle Cutout Diameter4.72"
Depth2.74"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.12ft³
Sealed F3120Hz
Vented Volume0.4ft³
Vented F355Hz
