Dayton Audio PS95-8 3-1/2" Point Source Full Range Driver 8 Ohm

Dayton Audio
Part #295-349

Dayton Audio PS95-8 3-1/2" Point Source Full Range Driver 8 Ohm

Dayton Audio
Part #295-349
Model: PS95-8
Dayton Audio's PS95-8 3-1/2" point source full range driver delivers the full spectrum of sound – including clear, natural highs – with excellent detail and articulation. No tweeter required!
Key Features
  • Copper pole cap in motor assembly reduces inductance and distortion
  • Detailed, natural sounding full-range audio performance without distortion
  • Classy copper-anodized phase plug spreads dispersion and avoids resonance
  • Low-mass voice coil and paper cone produce detailed, non-fatiguing sound
  • Non-resonant cast frame enhances clarity and dynamics
Similar items that may interest you:
See all items in Midrange / Midbass Drivers & Full-Range Speakers
Your Price: $27.98
MSRP: $36.99
Save $9.01 (24%)
Bulk Pricing
Quantity:Qty: 1-3 $27.98/ea
Quantity:Qty: 4+$25.18/ea
Order in the next 1 hr 32 min to ship today. Details

851In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio PS95-8 3-1/2" Point Source Full Range Driver 8 Ohm

The newest addition to Dayton Audio's successful family of Point Source full-range drivers, the PS95-8 model features a lightweight, curved-profile paper cone made of 100% natural fibers, for dynamic and articulate sound that extends from a punchy, detailed bass to the highest treble. The compact 3-1/2" size enables great sonic performance in small satellite speakers on the desktop, or in narrow "needle"-style tower cabinets for filling a larger room.

The copper-anodized aluminum phase plug of the PS95-8 is more than just beautiful – it provides enhanced dispersion and eliminates the resonance from a conventional dust cap. And the optimized, high-strength ferrite magnet structure features a copper pole cap that reduces resolution-sapping inductance and lowers distortion. Our smallest Point Source series full-range driver isn't small on engineering, or performance!

Product Details

BrandDayton Audio
ModelPS95-8
Part Number295-349
UPC848791001673
Unit of MeasureEach
Weight1.4

Product Specifications

Nominal Diameter3-1/2"
Bolt Circle Diameter3.4
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance8Ω
Frequency Response110 to 20,000Hz
Sensitivity85.56dB 2.83V/1m
Voice Coil Diameter0.79"

Thiele-Small Parameters

Resonant Frequency (Fs)119.8Hz
DC Resistance (Re)7.1Ω
Voice Coil Inductance (Le)0.63mH
Mechanical Q (Qms)7.33
Electromagnetic Q (Qes)0.8
Total Q (Qts)0.72
Compliance Equivalent Volume (Vas)0.03ft³
Mechanical Compliance of Suspension (Cms)0.79mm/N
BL Product (BL)3.83T·m
Diaphragm Mass Inc. Airload (Mms)2.2g
Maximum Linear Excursion (Xmax)2.5mm
Surface Area of Cone (Sd)28.3cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3.87"
Baffle Cutout Diameter3.05"
Depth2.1"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.04ft³
Sealed F3156Hz
Vented Volume0.12ft³
Vented F373Hz
