U.S. Acoustics Lisa 200 Watt 4 Channel Amplifier

U.S. Acoustics
Part #268-9004

U.S. Acoustics Lisa 200 Watt 4 Channel Amplifier

U.S. Acoustics
Part #268-9004
Model: Lisa

The US Acoustics Lisa 4-Channel Amplifier is a powerful and compact solution for enhancing your car audio system. This Class AB amplifier offers a durable build and advanced features, making it perfect for audio enthusiasts seeking reliable performance across a variety of possible installations.

Key Features
  • Class AB design for high-fidelity audio with minimal distortion
  • Angled terminals for clean, professional installations
  • Butterworth crossover filters for precise frequency tuning
  • Docking Pads to minimize vibration and extend amplifier lifespan
  • Comprehensive protection circuitry for thermal, short circuit, and DC offset issues
  • Compact dimensions for versatile installation in any vehicle
Your Price: $159.00
+ FREE SHIPPING
Bulk Pricing
Order in the next 3 hr 43 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

U.S. Acoustics Lisa 200 Watt 4 Channel Amplifier

Lisa

A Portrait of Audio Performance!

The Lisa amplifier embodies the classic Class AB design, providing warm, accurate audio reproduction with reduced distortion. The inclusion of angled terminals simplifies wiring and helps create a professional, show-quality setup.

Designed with practicality and durability in mind, the Lisa amplifier features Docking Pads to reduce vibration, which not only enhances reliability but also extends the amplifier’s lifespan. Butterworth crossover filters offer precise control over high-pass and low-pass frequencies, allowing you to tailor your audio system to your exact preferences. Comprehensive protection circuits safeguard against potential issues such as thermal overload, short circuits, and DC offset.

Tiny but mighty, the Lisa amplifier is compact enough to fit seamlessly into a variety of vehicle configurations. With its robust construction and versatile features, the US Acoustics Lisa 4-Channel Amplifier delivers powerful, reliable performance for car audio enthusiasts seeking exceptional sound quality and convenience.

Specifications

  • RMS per channel at 4 Ohms: 50 W x 4 CH
  • RMS per channel at 2 Ohms: 85 W x 4 CH
  • RMS Bridged Mono at 4 Ohms: 170 W x 2 CH
  • RMS Mono at 1 Ohm: N/A
  • Input Sensitivity: 200mV - 6.0V
  • Frequency Response: 10Hz - 30KHz +/- 0.5dB
  • Total Harmonic Distortion (THD): >0.01%
  • Signal-to-Noise Ratio (SNR): > 95 dB
  • Channel Separation: > 85 dB

  • Damping Factor @100Hz 4 ohm: > 100
  • Crossover Range: CH 3&4, CH 1&2
  • High Pass, 12dB/Octave: 15-500 Hz, 50-3K Hz
  • Low Pass, 24dB/Octave: 55-3.5K Hz
  • Subsonic: N/A
  • Variable Bass Boost (0 to +12 dB bass boost at 45 Hz): No
  • Wired remote bass control included: No
  • Phase Shift (0 - 180 degrees): No
  • Fusing: 2 x 25A
  • Size (L x W x H): 12.4" x 8.9" x 2.2"

Product Details

BrandU.S. Acoustics
ModelLisa
Part Number268-9004
UPC702458693178
Unit of MeasureEach
Weight8.15

Product Specifications

Input TypeRCA Line Level
Output Channels4
RMS Power Output (4 Ohms)50
Special Features2 ohm Stable-Bridgeable
