FaitalPRO HF102 1" Neodymium Compression Horn Driver 8 Ohm 2-Bolt

FaitalPRO
Part #294-1002

FaitalPRO HF102 1" Neodymium Compression Horn Driver 8 Ohm 2-Bolt

FaitalPRO
Part #294-1002
Model: HF102
The Italian-made HF102 neodymium compression driver from FaitalPRO provides high performance in a lightweight package.
Key Features
  • Dome shaped polymer diaphragm
  • Extended frequency response to 18,000 Hz
  • Lightweight design with neodymium ring motor
  • 2-bolt mounting pattern with M6 threads
  • Made in Italy
Your Price: $94.00
Bulk Pricing

Out of Stock

Ships in 7-10 Business Days
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO HF102 1" Neodymium Compression Horn Driver 8 Ohm 2-Bolt

FaitalPRO's HF102 1" compression horn driver is built using a dome ketone polymer dome diaphragm for smooth and extened frequency response that reaches out to 18,000 Hz. A rare earth neodymium magnet reduces overall weight to just over 1/2 a pound without sacrificing sensitivity. The HF102's radial phase plug increases dispersion, improving off-axis response. Two-bolt mounting pattern with M6 threads, spaced at 3" for use with many horns and waveguides. Made in Italy.

Specifications: • Power handling: 30 watts RMS with recommended crossover of 2,600 Hz, 12 dB/octave slope • VCdia: 0.98" • Impedance: 8 ohms • Frequency response: 1,500-20,000 Hz • SPL: 108 dB 1W/1m • Dimensions: 3.90" diameter x 1.69" depth • Bolt pattern: 2 x M6 • Weight: 0.66 lbs.

Product Details

BrandFaitalPRO
ModelHF102
Part Number294-1002
UPC848864011219
Unit of MeasureEach
Weight0.85

Product Specifications

Diaphragm MaterialPoly / Mylar
Exit Diameter1"
Mounting Type2-Bolt
Power Handling (RMS)30 Watts
Impedance8Ω
