Model: 10RS350-16
Faital Pro's flexible 10PR320-16 10" professional woofer can be used in everything from 2-way high efficiency designs to high output 2 or 4 x 10" bass guitar systems. With over 7 mm xmax this driver is capable of significant air displacement for high impact bass response. The rigid paper cone produces remarkably flat response with minimal resonances to deliver an extremely natural and accurate sound.
Key Features
  • Lightweight but powerful neodymium motor is perfect for portable multi driver systems
  • High excursion capability to deliver powerful low frequency response and maximum impact
  • 16-ohm impedance is perfect for 2 and 4 x 10" high output designs
  • 2.5" voice coil and fiberglass former can handle up to 300 watts RMS
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $272.00
+ FREE SHIPPING
Bulk Pricing
Order in the next 8 hr 52 min to ship today. Details

Only 1 In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 10PR320-16 10" Professional Neodymium Woofer 16 Ohm

Whether building a multi driver high efficiency system or a powerful bass guitar speaker, the 10PR320 10" professional woofer from Faital Pro is an excellent choice. With 7.27 mm xmax this driver can move an impressive amount of air for powerful low frequency and incredible impact. The strong neodymium motor gives the 10PR320 fantastic efficiency, but keeps weight to a minimum. High efficiency combined with the 300 watt RMS power handling ensures amazing overall output capability. The cone is constructed of waterproofed cellulose pulp with natural damping properties to deliver remarkably smooth and natural response. A rugged cast aluminum frame is used to withstand the beating that drivers can be exposed to in the touring sound environment. Finally, the 16 ohm impedance makes the 10PR320 perfect for use in 2 and 4 drivers systems for achieving extreme SPL levels. Faital Pro's 10PR320 is a truly flexible driver that will deliver outstanding performance and overall output.

Product Details

BrandFaitalPRO
Model10RS350-16
Part Number294-1324
UPC848864063164
Unit of MeasureEach
Weight7.05

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.69
Power Handling (RMS)300 Watts
Power Handling (MAX)600 Watts
Impedance16Ω
Frequency Response50 to 4,000Hz
Sensitivity95dB 2.83V/1m
Voice Coil Diameter2.56"

Thiele-Small Parameters

Resonant Frequency (Fs)50Hz
DC Resistance (Re)11.3Ω
Voice Coil Inductance (Le)0.98mH
Mechanical Q (Qms)3.3
Electromagnetic Q (Qes)0.43
Total Q (Qts)0.38
Compliance Equivalent Volume (Vas)1.56ft³
Mechanical Compliance of Suspension (Cms)0.3mm/N
BL Product (BL)16.7T·m
Diaphragm Mass Inc. Airload (Mms)33.6g
Maximum Linear Excursion (Xmax)7.27mm
Surface Area of Cone (Sd)321cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialAluminum
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter10.28"
Baffle Cutout Diameter9.06"
Depth4.33"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.5ft³
Sealed F3104.2Hz
Vented Volume1ft³
Vented F360Hz
