BUYOUT Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm

Name: Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm
Brand: Factory Buyouts
SKU: 299-2255
Price: 59.88 USD
Availability: InStock

Factory Buyouts

Part #299-2255

BUYOUT Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm

Factory Buyouts

Part #299-2255

Model: LA6-CBMR

Delivering high efficiency and controlled response, this sealed back midrange driver is engineered for use in 3-way high output line arrays. This wide band midrange driver offers incredible output capability with low distortion, making it ideal for use in any high output 3-way design.

Key Features

Truncated frame helps to minimize center to center distance for better off axis response in line arrays
2-layer 1-1/2” copper voice coil on a vented former can handle up to 150 watts RMS
500 to 5,400 Hz bandwidth is perfect for large 3-way systems
97 dB sensitivity ensures high SPL levels even without high power
Designed and assembled in the USA

Frequently Bought Together

This Product: Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm	$59.88
0.205" (16-14) Female Disconnect Crimp Terminal Blue 50 Pcs.	$6.39
Celestion CDX1-1446 1" High Frequency Compression Driver 8 Ohm	$29.88
Kustom Groove 215H Bi-Radial 90x90 Horn 1-3/8"-18 TPI	$4.88

Total Price: $101.03

This Product:Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm$59.88

0.205" (16-14) Female Disconnect Crimp Terminal Blue 50 Pcs.$6.39

Celestion CDX1-1446 1" High Frequency Compression Driver 8 Ohm$29.88

Kustom Groove 215H Bi-Radial 90x90 Horn 1-3/8"-18 TPI$4.88

4 ItemsTotal Price: $101.03

Overview

Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm

Originally designed for high output 3-way line arrays, this midrange driver will provide incredible performance in any larger 3-way system. The closed back frame means that this midrange does not require its own enclosure, making it easy to integrate into your next design. With a truncated frame the center-to-center distance between drivers can be kept to a minimum, helping to keep off-axis response under control when used in line arrays. A 1-1/2” voice coil wound on a vented polyimide former ensure high power handling, and with 97.8 dB sensitivity, this driver is capable of remarkable SPL levels. Weather you are designing a high output home, car, or professional sound system, this midrange will fit right in.

Designed and assembled in the USA.

Note: This new old stock driver is from a factory buyout. At such an economical price, these drivers won't last forever, quantities are limited.

Product Details
Brand	Factory Buyouts
Model	LA6-CBMR
Part Number	299-2255
UPC	848864077307
Unit of Measure	Each
Weight	6.95

Product Specifications
Nominal Diameter	6-1/2"
Bolt Circle Diameter	6.25
Power Handling (RMS)	150 Watts
Power Handling (MAX)	300 Watts
Impedance	8Ω
Frequency Response	500 to 5,400Hz
Sensitivity	97.8dB 2.83V/1m
Voice Coil Diameter	1.5"

Thiele-Small Parameters
Resonant Frequency (Fs)	460Hz
DC Resistance (Re)	6.3Ω
Voice Coil Inductance (Le)	0.33mH
Mechanical Q (Qms)	3.13
Electromagnetic Q (Qes)	1.24
Total Q (Qts)	0.89
Compliance Equivalent Volume (Vas)	0.01ft³
Mechanical Compliance of Suspension (Cms)	0.01mm/N
BL Product (BL)	11.1T·m
Diaphragm Mass Inc. Airload (Mms)	9g
Maximum Linear Excursion (Xmax)	0.2mm

Materials of Construction
Cone Material	Paper
Surround Material	Cloth
Voice Coil Wire Material	Copper
Voice Coil Former	Kapton® / Polyimide
Basket / Frame Material	Steel
Magnet Material	Ferrite

Mounting Information
Overall Outside Diameter	6.59"
Baffle Cutout Diameter	5.65"
Depth	2.77"
# Mounting Holes	4
