Dayton Audio RSS265HF-8 10" Reference Series HF Subwoofer 8 Ohm

Dayton Audio
Part #295-442

Dayton Audio RSS265HF-8 10" Reference Series HF Subwoofer 8 Ohm

Dayton Audio
Part #295-442
Model: RSS265HF-8
The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. As with the rest of the Reference Series, the main focus of the RSS265HF-8 10" subwoofer is ultra-low-distortion.
Key Features
  • Extensively vented motor eliminates power compression and allows quiet excursion
  • Lighter-weight black anodized aluminum cone minimizes moving mass
  • 2-layer coil for reduced back EMF
  • Triple shorting-ring motor for ultra-low distortion
  • Optimized for large enclosures
  • Highest quality materials throughout for long-lasting performance
Your Price: $199.98
+ FREE SHIPPING
MSRP: $227.99
Save $28.01 (12%)
Bulk Pricing
Quantity:Qty: 1-3 $199.98/ea
Quantity:Qty: 4+$184.48/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio RSS265HF-8 10" Reference Series HF Subwoofer 8 Ohm

The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. As with the rest of the Reference Series, the main focus of the RSS265HF-8 10" subwoofer is ultra-low-distortion. Second, third, and intermodulation distortion are kept extremely low by utilizing three short-circuit paths within the motor structure. A durable aramid fiber spider and extensive venting throughout provide quiet and uniform excursion. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look. Choose this High Fidelity (HF) version for home speaker systems when your priority is clean, low bass and you are not restricted by cabinet size.

Product Details

BrandDayton Audio
ModelRSS265HF-8
Part Number295-442
UPC844632088339
Unit of MeasureEach
Weight17.05

Product Specifications

Nominal Diameter10"
Power Handling (RMS)350 Watts
Power Handling (MAX)700 Watts
Impedance8Ω
Frequency Response25 to 2,000Hz
Sensitivity84.2dB 2.83V/1m
Voice Coil Diameter2.58"

Thiele-Small Parameters

Resonant Frequency (Fs)24.9Hz
DC Resistance (Re)6.5Ω
Voice Coil Inductance (Le)1.57mH
Mechanical Q (Qms)2.68
Electromagnetic Q (Qes)0.59
Total Q (Qts)0.49
Compliance Equivalent Volume (Vas)1.85ft³
Mechanical Compliance of Suspension (Cms)0.31mm/N
BL Product (BL)15T·m
Diaphragm Mass Inc. Airload (Mms)131g
Maximum Linear Excursion (Xmax)14.3mm
Surface Area of Cone (Sd)346.4cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.47"
Baffle Cutout Diameter9.25"
Depth5.37"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.1ft³
Sealed F340Hz
Vented Volume1.9ft³
Vented F323Hz
