Dayton Audio RS125-8 5" Reference Woofer

Dayton Audio
Part #295-353

Dayton Audio RS125-8 5" Reference Woofer

Dayton Audio
Part #295-353
Model: RS125-8
Dayton Audio Reference Series RS125-8 5" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.
Key Features
  • One of the lowest distortion, highest resolution driver series available
  • Low-distortion high-excursion motor system with two short-circuit paths
  • Compliant suspension and rigid black anodized aluminum cone for strong bass performance
  • Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
  • Designed and engineered in the USA
Your Price: $44.98
MSRP: $53.99
Save $9.01 (17%)
Bulk Pricing
Quantity:Qty: 1-3 $44.98/ea
Quantity:Qty: 4+$40.48/ea
Order in the next 0 hr 31 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio RS125-8 5" Reference Woofer

The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS125-8 5" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

Product Details

BrandDayton Audio
ModelRS125-8
Part Number295-353
UPC844632088735
Unit of MeasureEach
Weight2.15

Product Specifications

Nominal Diameter5"
Bolt Circle Diameter4.43
Power Handling (RMS)30 Watts
Power Handling (MAX)50 Watts
Impedance8Ω
Frequency Response65 to 5,400Hz
Sensitivity86.8dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)59.2Hz
DC Resistance (Re)6.2Ω
Voice Coil Inductance (Le)0.57mH
Mechanical Q (Qms)1.74
Electromagnetic Q (Qes)0.42
Total Q (Qts)0.34
Compliance Equivalent Volume (Vas)0.17ft³
Mechanical Compliance of Suspension (Cms)1.22mm/N
BL Product (BL)5.69T·m
Diaphragm Mass Inc. Airload (Mms)5.9g
Maximum Linear Excursion (Xmax)4mm
Surface Area of Cone (Sd)52.8cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter4.94"
Baffle Cutout Diameter3.7"
Depth2.17"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.07ft³
Sealed F3160Hz
Vented Volume0.22ft³
Vented F360Hz
