  • Visaton SC5-8 Shielded 1/2" Polycarbonate Tweeter 8 Ohm

Visaton SC5-8 Shielded 1/2" Polycarbonate Tweeter 8 Ohm

Visaton
Part #292-552

Visaton SC5-8 Shielded 1/2" Polycarbonate Tweeter 8 Ohm

Visaton
Part #292-552
Model: SC5 - 8
The 8005 SC5 1/2" dome tweeter from Visaton is a natural choice for speaker builders designing desktop recording monitors, surround sound multimedia speakers, or center channels.
Key Features
  • High power handling and shielded design
  • 4 kHz to 22 kHz usable frequency response
  • 90 dB sensitivity
  • Wide dispersion pattern
  • Rising response for top-end sparkle
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $14.15
MSRP: $18.99
Save $4.84 (25%)
Bulk Pricing
Quantity:Qty: 1-9 $14.15/ea
Quantity:Qty: 10-24 $13.73/ea
Quantity:Qty: 25+$13.14/ea
Ships next business day. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Visaton SC5-8 Shielded 1/2" Polycarbonate Tweeter 8 Ohm

Visaton's 8005 SC5 shielded 1/2" polycarbonate dome tweeter is built for superior off-axis response, high sensitivity, and a relatively flat frequency response from 4,000 Hz to 10,000 Hz. Above 10,000 Hz, the SC5 features a rising response to add ambiance and sparkle. The small size of this tweeter lends itself to be used in small 2-way monitors, center-channel speakers, and multimedia speakers where a shielded design is desired.

Product Details

BrandVisaton
ModelSC5 - 8
Part Number292-552
Unit of MeasureEach
Weight0.245

Product Specifications

Cone / Dome Diameter0.5"
Cutout Diameter1.89
Tweeter TypePoly / Mylar Dome
Power Handling (RMS)60 Watts
Impedance
Frequency Response1,500 to 22,000Hz
Sensitivity90dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)2000Hz

Mounting Information

Overall Outside Diameter2.03" x 2.03"
Depth0.89"
