  • PRV Audio MDX Series MDX1800.1 1 Ohm 1 Channel Mini Amplifier 1800W

NEW PRV Audio MDX Series MDX1800.1 1 Ohm 1 Channel Mini Amplifier 1800W

PRV Audio
Part #267-8080

NEW PRV Audio MDX Series MDX1800.1 1 Ohm 1 Channel Mini Amplifier 1800W

PRV Audio
Part #267-8080
Model: MDX1800.1 1 OHM

Perfect for high-performance systems with limited space, the MDX Series incorporates exclusive patented technologies to deliver high-definition sound quality in a small yet reliable package. Built with motorsports in mind, this tiny yet powerful amplifier is an excellent choice for your motorcycle, ATV, or slingshot.

Key Features
  • Small but mighty to deliver results without taking up space
  • 86% average efficiency delivers on output without straining your electrical system
  • Built in heatsink and cooling fan to keep the amp cool under the most demanding conditions
  • High level input to make connecting to a factory radio a breeze
  • A frequency response from 10-25,000Hz will let this amp handle any job you can give it
  • Engineered to endure vibration and still deliver a peak performance
  • An excellent choice for motorcycles, ATVs, and slingshots
NEW $169.91
+ FREE SHIPPING
MSRP: $212.39
Save $42.48 (20%)
Bulk Pricing
Order in the next 3 hr 10 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio MDX Series MDX1800.1 1 Ohm 1 Channel Mini Amplifier 1800W

  • This compact micro amplifier, with a small footprint and heavy-duty heatsink, is easy to install in vehicles, motorcycles, and 4-wheelers, measuring just 6.60″ W x 5.90″ L x 2.60″ H.
  • Designed for maximum efficiency, it delivers powerful output while reducing strain on your electrical system, ensuring high performance without rapid battery depletion.
  • Featuring monoblock 1-channel design, it delivers 1800 watts at 1 Ohm TRUE RMS, certified for full-range output using advanced Digital Class D Brazilian Technology. This allows you to wire multiple speakers and distribute power per channel effortlessly.
  • Equipped with 4-way protection circuitry, it safeguards against high voltage, low voltage, shortages, and overcurrent. Convenient built-in Power/Protection/Clip LED indicators on the top panel provide real-time system monitoring.

The latest surface-mount technology ensures optimal performance against vibration and delivers superior sound quality, making it a perfect choice for audio enthusiasts and competitors looking to create their dream system.

With a wide frequency response from 10 Hz to 25,000 Hz, this versatile amplifier is suitable for various applications, including subwoofers, midbass, midrange, full-range speakers, phenolic drivers, titanium drivers, and super tweeters.

Delivering 1800 Watts at 1 Ohm in a monoblock full-range configuration, the MDX Series is the ultimate solution for motorsport audio systems in custom motorcycles, ATVs, and Slingshots.

High output performance in a compact, space-saving design!

Equipped with a mini heavy-duty heatsink and built-in cooling fan to stay cool during intense playlists.

Weighing just 2.85 pounds, it offers an exceptional performance-to-weight ratio for custom systems.

Popular Installation configurations with this amplifier:

1 Channel Configuration for 8 Ohm Components

Its high-power output channels enable the installation of up to 8x 8 Ohm drivers or tweeters wired in parallel at 1 ohm, providing up to 225 watts of power to each component.

1 Channel Configuration for 4 Ohm components

Its high-power output channels enable the installation of up to 4x 4 Ohm drivers or tweeters wired in parallel at 1 ohm, providing up to 450 watts of power to each component.

Before Installing

You must follow the instructions for the product’s installation to guarantee optimal performance. If you have any questions, get in touch with us. Before using the amplifier, always follow these guidelines:

  • Make sure the amplifier is switched off before adding or removing any connections. This prevents possible damage to equipment.
  • Keep all cables as far away as possible from the ignition cables, electronic injection modules and starter switch since they may cause noise interference; Minimum recommended installation distance between amplifier is 1.25”.
  • Always use OFC 4 AWG Copper wire for power and ground and minimum of 12 AWG speaker wire and good quality connectors. Copper-clad aluminum wire (CCAW) must not be used. This guarantees reliability and performance.
  • To avoid damaging the cables, make sure that they do not touch sharp metal edges. Important: For this amp use a 100A fuse 12 inches away from the battery as a safety precaution.

    The power rating data is based on equipment from the PRV Audio Group laboratory. Rated power tested with 60Hz to 1KHz sinusoidal signal and THD <= 1%, with resistant load referring to the indicated measurements. The electronic components and the manufacturing process can present manufacturing variations, thus leading to a variation in the measurements made. This amplifier is designed to perform on music applications ( with speakers ), any load test ( resistant load ) is not recommended.

Specifications

  • Impedance: 1 Ohm
  • Channels: 1 Channel
  • Rated RMS Power at 14.0 V at 1 Ohm: 1x 1800 Watts RMS
  • Rated RMS Power at 14.0 V at 2 Ohm: 1x 1100 Watts RMS
  • Average Efficiency: 86%
  • Operating Voltage: 9 to 16 Volts
  • Musical Current Draw: 75 A
  • Minimal Power Wire Input: (OFC) 4 Gauge wires
  • Built-in Crossover: Variable HPF 5 Hz - 80Hz & LPF 50Hz - 1kHz
  • Minimal Speaker Wire Output: 14 Gauge
  • Frequency Response(-3dB): 10 – 25,000 Hz
  • Min. Input Sensitivity for Max. Output: 0.2 to 2v
  • Signal Input: RCA Cables
  • Signal to Noise: >90 dB
  • Protection System: Low & High Supply Voltage / Shortage on Output / Low Impedance on Output
  • Heat Sink Type: Mini Heavy Duty Cast Aluminum
  • Dimensions ( Width x Depth x Height ): 6.6″ x 5.90″ x 2.60″
  • Weight 2.85 lbs.

Product Details

BrandPRV Audio
ModelMDX1800.1 1 OHM
Part Number267-8080
UPC810075524215
Unit of MeasureEach
Weight3.3

Product Specifications

Input TypeRCA Line Level-Speaker Level
Output Channels1
Special Features1 ohm Stable-2 ohm Stable
