PRV Audio D3220Ti-Nd 2" Titanium Neodymium Horn Compression Driver 8 Ohm 4-Bolt

PRV Audio
Part #294-2851

PRV Audio D3220Ti-Nd 2" Titanium Neodymium Horn Compression Driver 8 Ohm 4-Bolt

PRV Audio
Part #294-2851
Model: D3220Ti-Nd

Upgrade your speaker cabinets today using PRV Audio's D3220TiH-Nd 2" neodymium compression driver. High output and smooth frequency response allows you to use this horn driver in almost any high output audio application: pro, home, or car. Standard 4-bolt pattern and weighs less than 5 lbs.

Key Features
  • Kapton® former and titanium diaphragm for neutral sound
  • Designed for high frequency use 1,600 to 19,000 Hz
  • High 108 dB sensitivity with lightweight neodymium motor
  • Four M6 bolt holes for secure horn coupling with included mounting bolts
  • Spring-loaded speaker terminals
Similar items that may interest you:
See all items in Horn Drivers
Your Price: $139.91
+ FREE SHIPPING
MSRP: $174.89
Save $34.98 (20%)
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio D3220Ti-Nd 2" Titanium Neodymium Horn Compression Driver 8 Ohm 4-Bolt

PRV Audio's D3220Ti-Nd 2" pure titanium, neodymium compression driver offers a surprisingly smooth, neutral sound not normally found in titanium compression drivers at this price point, and weighs less than 5 pounds. In fact, the D3220Ti-Nd competes with drivers costing up to three times as much! A 2" exit and four bolt pattern makes this the perfect upgrade horn driver for many popular professional audio speaker cabinets.

High output mobile audio enthusiasts choose the PRV Audio D3220Ti-Nd for extreme SPL car audio competitions in South America, while DJs use it in high SPL speaker cabinets for entertaining crowds that number in the thousands. The neodymium motor helps to keep cabinets as light as possible, even when using this large format horn driver.

The pure titanium diaphragm is attached to a 3" diameter copper voice coil with Kapton® former for the lowest possible moving mass without sacrificing power handling. This allows for an amazing 108 dB of output with only 1 watt (2.83V) of input power, when measured at one meter, for use in even the loudest of environments! Mounting hardware is included

Specifications: • Power handling: 110 watts RMS with recommended crossover of 1,600 Hz, 12 dB/octave slope • VCdia: 3" • Impedance: 8 ohms • Frequency response: 1,600-19,000 Hz • SPL: 110 dB 1W/1m • Dimensions: 4.88" diameter x 2.2" depth • Net weight: 4.72 lbs. • Mounting: 4 x M6 bolt holes on a 4" diameter (hardware included) • Replacement diaphragm available (please see Related Items).

Product Details

BrandPRV Audio
ModelD3220Ti-Nd
Part Number294-2851
UPC799928733816
Unit of MeasureEach
Weight4.85

Product Specifications

Diaphragm MaterialTitanium
Exit Diameter2"
Mounting Type4-Bolt
Power Handling (RMS)110 Watts
Impedance8Ω
