PRV Audio 8MB700FT-NDY 8" Neodymium Speaker 8 Ohms

1 Question, 9 Answers or
PRV Audio
Part #294-2773

PRV Audio 8MB700FT-NDY 8" Neodymium Speaker 8 Ohms

PRV Audio
Part #294-2773
Model: 8MB700FT-NDY
1 Question, 9 Answers or
Specially designed for more power handling and less distortion, PRV Audio's 8MB700FT-NDY 8" midrange is an excellent addition to any high output sound system. With 98 dB sensitivity, this driver is capable of generating a lot of output even with moderate input power.
Key Features
  • Powerful neodymium motor allow minimum weight and high efficiency
  • Composite non-pressed paper cone for reduced break-up and smooth response
  • Large 2-1/2" voice coil allows for the high 350 watt power handling and high BL
  • Extensive venting keeps air moving across the coil for low power compression
Your Price: $159.91
+ FREE SHIPPING
MSRP: $199.89
Save $39.98 (20%)
Bulk Pricing
Ships next business day. Details

10In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 8MB700FT-NDY 8" Neodymium Speaker 8 Ohms

With high efficiency and power handling, the 8MB700FT-NDY 8" midrange from PRV Audio is capable of incredible overall output while producing very low distortion. Thanks to it's output capability and wide frequency response, this driver is perfect for pairing with high frequency compression drivers. For low weight a high efficiency the 8MB700FT uses an FEA optimized neodymium motor. Extensive venting through the motor assembly and frame keep the large 2-1/2" voice coil cool to handle 350 watts of power with low power compression. AA special composite pulp paper cone and accordion surround delivers natural response with low distortion even when driven to its limits. Suitable with high efficiency home designs, professional sound reinforcement, and even extreme SPL automotive systems, the 8MB700FT-NDY is one impressive midrange driver.

Product Details

BrandPRV Audio
Model8MB700FT-NDY
Part Number294-2773
UPC602938022569
Unit of MeasureEach
Weight4.8

Product Specifications

Nominal Diameter8"
Bolt Circle Diameter7.75
Power Handling (RMS)350 Watts
Power Handling (MAX)700 Watts
Impedance8Ω
Frequency Response70 to 5,600Hz
Sensitivity98dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)69.97Hz
DC Resistance (Re)5.2Ω
Voice Coil Inductance (Le)0.34mH
Mechanical Q (Qms)2.78
Electromagnetic Q (Qes)0.33
Total Q (Qts)0.3
Compliance Equivalent Volume (Vas)0.66ft³
Mechanical Compliance of Suspension (Cms)0.217mm/N
BL Product (BL)12.78T·m
Diaphragm Mass Inc. Airload (Mms)23.79g
Maximum Linear Excursion (Xmax)3.65mm
Surface Area of Cone (Sd)249cm²

Materials of Construction

Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter8.2"
Baffle Cutout Diameter7.3"
Depth3.66"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Vented Volume0.6ft³
Vented F364Hz
