Lanzar MAXP154D 15" 2000 Watt Woofer

Lanzar
Part #267-7138

Lanzar MAXP154D 15" 2000 Watt Woofer

Lanzar
Part #267-7138
Model: MAXP154D
Lanzar's MAXP154D 15" woofer has a bumped vented motor structure and custom designed rubber magnet boot for extended excursion.
Key Features
  • 2.5'' dual layer high temperature Kapton voice coil
  • Specially treated foam edge suspension
  • Bumped vented motor structure for extended excursion
  • Peak power of 2,000 watts
Your Price: $89.98
MSRP: $175.99
Save $86.01 (49%)
Bulk Pricing
Quantity:Qty: 1-3 $89.98/ea
Quantity:Qty: 4+$88.29/ea

Back-Ordered

Estimated back in stock 12/27/2024
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Lanzar MAXP154D 15" 2000 Watt Woofer

The Lanzar MAXP154D 15" woofer has a peak power rating of 2,000 watts, and a black non-pressed paper cone with a specially treated foam edge suspension. Features a reinforced polymer basket with hex key input terminal. Bumped vented motor structure and custom designed rubber magnet boot for extended excursion. 2.5'' dual layer high temperature Kapton voice coil.

Product Details

BrandLanzar
ModelMAXP154D
Part Number267-7138
UPC068888878845
Unit of MeasureEach
Weight19.45

Product Specifications

Nominal Diameter15"
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Sensitivity89dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)30Hz
Mechanical Q (Qms)5
Electromagnetic Q (Qes)0.9
Total Q (Qts)0.75
Compliance Equivalent Volume (Vas)6.02ft³

Materials of Construction

Cone MaterialPaper
Surround MaterialFoam
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialPolymer
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.8"
Baffle Cutout Diameter14"
Depth9"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3ft³
Sealed F339.7Hz
Vented Volume4.5ft³
Vented F331.3Hz
