LaVoce WAF154.02 15" Subwoofer 8 Ohm

LaVoce
Part #293-722

LaVoce WAF154.02 15" Subwoofer 8 Ohm

LaVoce
Part #293-722
Model: WAF154.02
The LaVoce WAF154.02 is an impressive 15" woofer that features an impressive aluminum basket which provides exceptional cooling. The excellent 97.5 dB sensitivity is perfect for mating to other high-efficiency drivers.
Key Features
  • FEM optimized Ferrite motor and suspensions
  • Optimized cooling system for reliable performance
  • Large 4" voice coil for improved power handling
  • Resonance-free, heavy-duty aluminum basket demonstrates excellent build quality
Your Price: $239.00
+ FREE SHIPPING
MSRP: $356.72
Save $117.72 (33%)
Bulk Pricing
Ships next business day. Details

Only 2 In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

LaVoce WAF154.02 15" Subwoofer 8 Ohm

The LaVoce WAF154.02 is an impressive 15" woofer that features an impressive aluminum basket which provides exceptional cooling. The excellent 97.5 dB sensitivity is perfect for mating to other high-efficiency drivers. The WAN154.02 also features a double silicone spider for improved linearity. The gasket on this driver allows it to be rear mounted easily, providing additional installation flexibility. To add to the versatility of this driver, the cone has been treated to be waterproof, making it ideal for outdoor cabinets.

Product Details

BrandLavoce
ModelWAF154.02
Part Number293-722
UPC848864057446
Unit of MeasureEach
Weight27.7

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.69
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Frequency Response40 to 1,000Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)40Hz
DC Resistance (Re)6Ω
Voice Coil Inductance (Le)1.7mH
Mechanical Q (Qms)7.2
Electromagnetic Q (Qes)0.42
Total Q (Qts)0.39
Compliance Equivalent Volume (Vas)4.63ft³
Mechanical Compliance of Suspension (Cms)0.1mm/N
BL Product (BL)23.1T·m
Diaphragm Mass Inc. Airload (Mms)148.8g
Maximum Linear Excursion (Xmax)7.9mm
Surface Area of Cone (Sd)830cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.47"
Baffle Cutout Diameter13.93"
Depth6.8"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.5ft³
Sealed F362.1Hz
Vented Volume3.75ft³
Vented F343.6Hz
