BUYOUT Eminence Professional 15" Paper Cone Woofer 3 Ohm

Name: Eminence Professional 15" Paper Cone Woofer 3 Ohm
Brand: Factory Buyouts
SKU: 299-2251
Price: 79.88 USD
Availability: InStock
Rating: 4.5 (6 reviews)

Read 6 Reviews | 4 Questions, 9 Answers or

Factory Buyouts

Part #299-2251

BUYOUT Eminence Professional 15" Paper Cone Woofer 3 Ohm

Factory Buyouts

Part #299-2251

Model: Kappa 15

Read 6 Reviews | 4 Questions, 9 Answers or

With a unique 3 ohm impedance, this Eminence 15” professional woofer is a perfect for use in dual 15” pro sound speakers and bass guitar amplifiers. Featuring a pressed paper cone, damped accordion surround, and strong motor, this driver produces smooth response and extremely high sensitivity. Factor in the 450 watts RMS power handling and you can expect incredible output capability.

Key Features

3 ohm impedance makes this driver ideal for use in dual 15” designs
Large 3” diameter voice coil handles up to 450 watts RMS
Vented pole piece and large ferrite motor helps dissipate heat and minimize power compression
Naturally damped paper cone and cloth surround delivers smooth response
Made in the USA

Frequently Bought Together

This Product: Eminence Professional 15" Paper Cone Woofer 3 Ohm	$79.88
0.205" (16-14) Female Disconnect Crimp Terminal Blue 50 Pcs.	$6.39
Audtek 50 ft. 14 AWG OFC Speaker Wire	$23.98
Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm	$59.88

Total Price: $170.13

This Product:Eminence Professional 15" Paper Cone Woofer 3 Ohm$79.88

0.205" (16-14) Female Disconnect Crimp Terminal Blue 50 Pcs.$6.39

Audtek 50 ft. 14 AWG OFC Speaker Wire$23.98

Eminence 6-1/2" Line Array Series Sealed Back Midrange Speaker 8 Ohm$59.88

4 ItemsTotal Price: $170.13

Overview

Eminence Professional 15" Paper Cone Woofer 3 Ohm

This 3 ohm 15” paper cone professional woofer, built by Eminence Speakers, offers extreme output capability and natural response. The naturally damped paper cone and cloth surround keep unwanted response peaks under control, making it easy to integrate a high frequency driver into your design. The large ferrite motor and lightweight cone assembly results in a sensitivity of 100 dB giving this 15” incredible output levels. Finally, the 3” voice coil and vented pole piece can handle up to 450 watts RMS before suffering from heat related issues heat issues like power compression or glue failure. With its 3 ohm impedance, this is an excellent driver for use high output dual 15” designs.

Made in the USA

Note: This new old stock driver is from a factory buyout. At such an economical price, these drivers won't last forever, quantities are limited.

Product Details
Brand	Factory Buyouts
Model	Kappa 15
Part Number	299-2251
UPC	848864077260
Unit of Measure	Each
Weight	20

Product Specifications
Nominal Diameter	15"
Bolt Circle Diameter	14.625
Power Handling (RMS)	450 Watts
Power Handling (MAX)	900 Watts
Impedance	3Ω
Frequency Response	60 to 2,500Hz
Sensitivity	100.5dB 2.83V/1m
Voice Coil Diameter	3"

Thiele-Small Parameters
Resonant Frequency (Fs)	27Hz
DC Resistance (Re)	2.8Ω
Voice Coil Inductance (Le)	0.83mH
Mechanical Q (Qms)	7.46
Electromagnetic Q (Qes)	0.3
Total Q (Qts)	0.29
Compliance Equivalent Volume (Vas)	12.6ft³
Mechanical Compliance of Suspension (Cms)	0.34mm/N
BL Product (BL)	12.7T·m
Diaphragm Mass Inc. Airload (Mms)	99.2g
Maximum Linear Excursion (Xmax)	3mm
Surface Area of Cone (Sd)	862.6cm²

Materials of Construction
Cone Material	Paper
Surround Material	Cloth
Voice Coil Wire Material	Copper
Voice Coil Former	Kapton® / Polyimide
Basket / Frame Material	Steel
Magnet Material	Ferrite

Mounting Information
Overall Outside Diameter	15.16"
Baffle Cutout Diameter	13.875"
Depth	5.75"
# Mounting Holes	8

Parts Express Staff Recommended Enclosure Volume
Sealed Volume	1.7ft³
Sealed F3	80Hz
Vented Volume	2.5ft³
Vented F3	55Hz
