Weighing in at less than 4 pounds, this 4 ohm 10" paper cone woofer from Eminence Speakers uses a powerful neodymium magnet to minimize weight while maximizing performance. This versatile driver combines high efficiency, good excursion, and low distortion making it suitable for almost any high output designs including studio monitors, professional line arrays, and even bass guitar amplifiers.
Key Features
  • Integrated heatsink and 2-1/2" diameter voice coil to handle up to 250 watts RMS
  • Over 96 dB sensitivity means that you can expect high SPL even from lower power systems
  • High energy neodymium motor allows minimal weight without sacrificing performance
  • Vented pole piece keeps air moving across the voice coil to dissipate excess heat
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
BUYOUT $79.88
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence Professional 10" Paper Cone Neodymium Woofer 4 Ohm

This 4 ohm 10" paper cone woofer from Eminence Speakers is designed to deliver exceptional performance while minimizing weight. Weighing less than 4 pounds, this woofer utilizes a powerful neodymium magnet to maintain maximum performance. Its high efficiency, good excursion, and low distortion make it suitable for various high output designs, including studio monitors, professional line arrays, and bass guitar amplifiers.

Equipped with an integrated heatsink and a 2-1/2" diameter voice coil, this woofer can handle up to 250 watts RMS. With over 96 dB sensitivity, even lower power systems can expect high sound pressure level (SPL). The high energy neodymium motor ensures that weight is kept to a minimum without compromising performance. Additionally, the vented pole piece facilitates continuous airflow across the voice coil to effectively dissipate excess heat.

This 10" paper cone woofer is engineered to provide exceptional performance and durability. Combining technical precision and meticulous design, this woofer is the ideal choice for those seeking high output and reliable sound reproduction in professional audio applications.

Note: This new old stock driver is from a factory buyout. At such an economical price, these drivers won't last forever, quantities are limited.

Product Details

BrandFactory Buyouts
ModelDG09-10-034
Part Number299-2254
UPC848864077291
Unit of MeasureEach
Weight3.9

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.75
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance4Ω
Frequency Response50 to 4,000Hz
Sensitivity96.4dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)49.6Hz
DC Resistance (Re)3.8Ω
Voice Coil Inductance (Le)0.56mH
Mechanical Q (Qms)4.86
Electromagnetic Q (Qes)0.41
Total Q (Qts)0.38
Compliance Equivalent Volume (Vas)1.56ft³
Mechanical Compliance of Suspension (Cms)0.26mm/N
BL Product (BL)10.7T·m
Diaphragm Mass Inc. Airload (Mms)39.4g
Maximum Linear Excursion (Xmax)4.5mm
Surface Area of Cone (Sd)345cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter10.25"
Baffle Cutout Diameter9.15"
Depth4.375"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.6ft³
Sealed F3100Hz
Vented Volume1.25ft³
Vented F353Hz
