Dayton Audio RSS460HO-4 18" Reference Series HO Subwoofer 4 ohm

Dayton Audio
Part #295-472

Dayton Audio RSS460HO-4 18" Reference Series HO Subwoofer 4 ohm

Dayton Audio
Part #295-472
Model: RSS460HO-4
The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look.
Key Features
  • Extensively vented motor eliminates compression and allows quiet excursion
  • Extra-thick black anodized aluminum cone for maximum rigidity
  • Triple shorting ring motor for ultra-low distortion
  • 4-layer coil for high power handling
  • Optimized parameters for relatively small enclosures
  • Highest quality materials throughout for long-lasting performance
Similar items that may interest you:
See all items in Subwoofer Drivers
Your Price: $399.98
+ FREE SHIPPING
MSRP: $491.99
Save $92.01 (19%)
Bulk Pricing
Quantity:Qty: 1-3 $399.98/ea
Quantity:Qty: 4+$386.98/ea

Back-Ordered

Estimated back in stock 9/6/2024
Alert Me When Available
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio RSS460HO-4 18" Reference Series HO Subwoofer 4 ohm

The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. As with the rest of the Reference Series, the main focus of these subwoofers is ultra-low-distortion. Second, third, and intemodulation distortion are kept extremely low by utilizing three short-circuit paths within the motor structure. A durable aramid fiber spider and extensive venting throughout provide quiet and uniform excursion. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look.

 A knock-down 4.0 cubic foot subwoofer cabinet built specifically for the RSS460HO-4 is available here.

The Dayton Audio RSS460HO-4 is used in the following kits:

Dayton Audio 18" Reference Series HO Subwoofer and Cabinet Bundle

Build the ultimate in high fidelity bass reproduction using this superior subwoofer cabinet and the Dayton Audio RSS460HO-4 Reference Series 18" High Output subwoofer. Save over $40 off original retail price when you purchase this knock-down enclosure and subwoofer package.

VIEW KIT

Passive Dayton Audio Reference 18" with Dual Passive Radiator Subwoofer Kit

If you need extreme output capabilities, gut wrenching low-end response, and minimal distortion, then this is the sub kit for you. Using Dayton Audio's massive RSS460HO-4 18" driver paired up with two of the RSS460-PR passive radiators, this subwoofer kit is capable of seeming endless output capability with unbelievable low frequency extension. Beyond that, thanks to the low distortion design of the driver and added damping of the passive radiators, this kit produces remarkably low distortion levels.

VIEW KIT

Learn More
Request Quote



Product Details

BrandDayton Audio
ModelRSS460HO-4
Part Number295-472
UPC844632099618
Unit of MeasureEach
Weight42.35

Product Specifications

Nominal Diameter18"
Power Handling (RMS)900 Watts
Power Handling (MAX)1800 Watts
Impedance4Ω
Frequency Response20 to 500Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)18.8Hz
DC Resistance (Re)3.2Ω
Voice Coil Inductance (Le)2.24mH
Mechanical Q (Qms)4.05
Electromagnetic Q (Qes)0.35
Total Q (Qts)0.32
Compliance Equivalent Volume (Vas)9.61ft³
Mechanical Compliance of Suspension (Cms)0.14mm/N
BL Product (BL)23.4T·m
Diaphragm Mass Inc. Airload (Mms)499g
Maximum Linear Excursion (Xmax)12.75mm
Surface Area of Cone (Sd)1164cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter18.17"
Baffle Cutout Diameter16.69"
Depth8.94"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.9ft³
Sealed F347Hz
Vented Volume3.6ft³
Vented F329Hz
