Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

Dayton Audio
Part #275-106

Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

Dayton Audio
Part #275-106
Model: ND16FA-4
Dayton Audio's ND16FA-4 5/8" soft dome tweeter is perfect for use in compact 2-way systems such as desktop, surround, or portable speaker systems. With smooth response from 4,000 to 20,000 Hz this tweeter is ideal for adding more top end to many full-range drivers.
Key Features
  • Ferrofluid enhances power handling and helps damp resonance
  • Powerful neodymium motor keeps tweeter small with impressive efficiency
  • Compact faceplate is perfect for minimal center-to-center distances
  • Easy installation, front mount pressfit design
  • Perfect for placement in car A-pillars
Your Price: $8.29
MSRP: $14.99
Save $6.70 (45%)
Bulk Pricing
Quantity:Qty: 1-3 $8.29/ea
Quantity:Qty: 4+$7.46/ea
Order in the next 14 hr 10 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

The versatile ND16FA-4 5/8" soft dome tweeter from Dayton Audio has the sensitivity, smoothness, and power handling for use in a 2-way design with most small woofers. The compact faceplate allows minimal center-to-center distances making these a great choice for use in 2-way designs with high crossover points. With 4-ohm impedance, this tweeter is suitable for use in both home and automotive applications. Thanks to the Ferrofluid cooled voice coil, the ND16FA-4 can handle an impressive amount of power and has excellent damping for extremely accurate response.

Product Details

BrandDayton Audio
ModelND16FA-4
Part Number275-106
UPC848791004742
Unit of MeasureEach
Weight0.05

Product Specifications

Cone / Dome Diameter0.625"
Cutout Diameter1.42
Tweeter TypeSoft Dome
Power Handling (RMS)30 Watts
Impedance4Ω
Frequency Response4,000 to 20,000Hz
Sensitivity93dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)2246Hz
DC Resistance (Re)3.17Ω
Voice Coil Inductance (Le)0.03mH
Mechanical Q (Qms)3.71
Electromagnetic Q (Qes)3.46
Total Q (Qts)1.79

Mounting Information

Overall Outside Diameter1.77"
Depth0.45"
