CLEARANCE Dayton Audio LS12-44 12" Low Profile Subwoofer Dual 4 Ohm

Dayton Audio
Part #295-253

CLEARANCE Dayton Audio LS12-44 12" Low Profile Subwoofer Dual 4 Ohm

Dayton Audio
Part #295-253
Model: LS12-44
At a depth of less than 4", Dayton Audio's LS12-44 12" low profile subwoofer fits into shallow spaces that ordinary subs wouldn't dream of attempting! Dual 2" 4 ohm coils provide flexible wiring, while the flat cone and innovative suspension support 10 mm of Xmax!
Key Features
  • Innovative low-profile subwoofer -- less than 4" thick!
  • 10 mm Xmax for uncompromised bass performance
  • Dual 4 ohm voice coils, 6 layers total, for high BL force and multiple wiring options
  • Rigid flat honeycomb fiberglass cone maintains its integrity under severe conditions
  • Low distortion ferrite motor with dual aluminum shorting rings keeps the bass clean and powerful
  • Balanced rubber double-roll surround design improves stability and control
Similar items that may interest you:
See all items in Subwoofer Drivers

Overview

Dayton Audio LS12-44 12" Low Profile Subwoofer Dual 4 Ohm

Back with a new and improved design, Dayton Audio's shallow subwoofers let you put more bass into less space! The new LS12-44 Low Profile Subwoofer from Dayton Audio provides over 10 mm of controlled excursion, for bass that hits hard and goes deep -- even in places ordinary subwoofers just won't fit! These drivers are perfect for installation in walls, floors, and ceilings, or in limited-clearance automotive applications like the narrow space behind pickup truck seats. They might even fit under your chair or behind your sofa!

Innovative design makes the shallow form factor of the LS Series low profile subwoofers possible. A flat, rigid piston made of aluminum honeycomb with glass fiber skins replaces the conventional cone of most subwoofers, and a balanced double-roll surround design maximizes the stability of the moving structure, even at high excursion, preventing mechanical noise. The motor assembly is optimized for symmetrical motion and low distortion, featuring dual heavy-gauge aluminum shorting rings for low inductance and fast, impactful bass. Lastly, a 6-layer dual voice coil ensures maximum available force from the compact motor, which features high-grade ceramic ferrite magnetic material, and enables 2 ohm or 8 ohm wiring.

Nothing has been sacrificed in creating these truly next-generation shallow subwoofers, capable of over 10 mm of linear excursion form an ultra-slim package. Trust the LS Series subwoofer drivers to deliver years of rugged, long-lasting enjoyment, wherever you install them. Wherever you would like to add more bass, Dayton Audio has you covered.

Note: All parameters derived with voice coils wired in series.

Learn More
Request Quote

Product Details

BrandDayton Audio
ModelLS12-44
Part Number295-253
UPC848791001611
Unit of MeasureEach
Weight11.55

Product Specifications

Nominal Diameter12"
Bolt Circle Diameter11.69
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance8Ω
Frequency Response28 to 300Hz
Sensitivity88dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)33.7Hz
DC Resistance (Re)7.5Ω
Voice Coil Inductance (Le)5.34mH
Mechanical Q (Qms)4.94
Electromagnetic Q (Qes)0.56
Total Q (Qts)0.51
Compliance Equivalent Volume (Vas)1.99ft³
Mechanical Compliance of Suspension (Cms)0.13mm/N
BL Product (BL)21.7T·m
Diaphragm Mass Inc. Airload (Mms)166g
Maximum Linear Excursion (Xmax)10mm
Surface Area of Cone (Sd)547.3cm²

Materials of Construction

Cone MaterialFiberglass
Surround MaterialRubber
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.4"
Baffle Cutout Diameter11.1"
Depth3.88"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.1ft³
Sealed F361Hz
Vented Volume2.5ft³
Vented F329Hz
