Dayton Audio LS10-44 10" Low Profile Subwoofer Dual 4 Ohm

Dayton Audio
Part #295-251

Dayton Audio LS10-44 10" Low Profile Subwoofer Dual 4 Ohm

Dayton Audio
Part #295-251
Model: LS10-44
At a depth of less than 3.4", Dayton Audio's LS10-44 10" low profile subwoofer fits into shallow spaces that ordinary subs wouldn't dream of attempting! Dual 2" 4 ohm coils provide flexible wiring, while the flat cone and innovative suspension support 10 mm of Xmax!
Key Features
  • Innovative low-profile subwoofer – less than 3.4" thick!
  • 10 mm Xmax guarantees uncompromised bass performance
  • Dual 4 ohm voice coils, 6 layers total, for high BL force and multiple wiring options
  • Rigid flat honeycomb fiberglass cone maintains linearity and high impact
  • Low distortion ferrite motor with dual aluminum shorting rings
  • Balanced rubber double-roll surround design improves stability and control
Similar items that may interest you:
See all items in Subwoofer Drivers
Your Price: $134.98
+ FREE SHIPPING
MSRP: $178.99
Save $44.01 (25%)
Bulk Pricing
Quantity:Qty: 1-3 $134.98/ea
Quantity:Qty: 4+$116.98/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio LS10-44 10" Low Profile Subwoofer Dual 4 Ohm

Dayton Audio's shallow subwoofers let you put more bass into less space! The new LS10-44 Low Profile Subwoofer from Dayton Audio provides over 10 mm of controlled excursion, for bass that hits hard and goes deep -- even in places ordinary subwoofers just won't fit! These drivers are perfect for installation in walls, floors, and ceilings, or in limited-clearance automotive applications like the narrow space behind pickup truck seats. They might even fit under your chair or behind your sofa!

Innovative design makes the shallow form factor of the LS Series low profile subwoofers possible. A flat, rigid piston made of aluminum honeycomb with glass fiber skins replaces the conventional cone of most subwoofers, and a balanced double-roll surround design maximizes the stability of the moving symmetrical motion and minimizes distortion. The LS10-44 also features dual heavy-gauge aluminum shorting rings for low inductance and fast, impactful bass. Lastly, a 6-layer dual voice coil ensures maximum available force from the compact motor, featuring high-grade ceramic ferrite magnetic material, and enables 2 ohm or 8 ohm wiring.

Nothing has been sacrificed in creating these truly next-generation shallow subwoofers, capable of over 10 mm of linear excursion from an ultra-slim package. Trust the LS Series subwoofer drivers to deliver years of rugged, long-lasting enjoyment, wherever you install them. Wherever you would like to add more bass, Dayton Audio has you covered.

Note: All parameters derived with voice coils wired in series.

Learn More
Request Quote

Product Details

BrandDayton Audio
ModelLS10-44
Part Number295-251
UPC848791001604
Unit of MeasureEach
Weight10.85

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter10.125
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance8Ω
Frequency Response30 to 300Hz
Sensitivity86.5dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)34.3Hz
DC Resistance (Re)7.4Ω
Voice Coil Inductance (Le)5.25mH
Mechanical Q (Qms)5.15
Electromagnetic Q (Qes)0.47
Total Q (Qts)0.43
Compliance Equivalent Volume (Vas)1.08ft³
Mechanical Compliance of Suspension (Cms)0.16mm/N
BL Product (BL)21.1T·m
Diaphragm Mass Inc. Airload (Mms)132g
Maximum Linear Excursion (Xmax)10mm
Surface Area of Cone (Sd)366.4cm²

Materials of Construction

Cone MaterialFiberglass
Surround MaterialRubber
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.75"
Baffle Cutout Diameter9.4375"
Depth3.32"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.62ft³
Sealed F373Hz
Vented Volume1.4ft³
Vented F332Hz
