Ciare CMR160 6.5" Full-Range Driver 4 Ohm

5 Questions, 15 Answers or
Ciare
Part #293-108

Ciare CMR160 6.5" Full-Range Driver 4 Ohm

Ciare
Part #293-108
Model: CMR160
5 Questions, 15 Answers or

The Ciare CMR160's sleek and modern design makes it a perfect complement to any home, car or professional sound system. Its lightweight and compact size make it easy to install and incorporate into any audio setup.

Key Features
  • Oversized ferrite motor for higher Bl and above average sensitivity
  • 1.5" voice coil for up to 200 watt power handling
  • Premium upgrade for car, boat, motorcycle, ATV and more
Your Price: $92.18
MSRP: $122.91
Save $30.73 (25%)
Bulk Pricing
Order in the next 1 hr 45 min to ship today. Details

4In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Ciare CMR160 6.5" Full-Range Driver 4 Ohm

The Ciare CMR160 6.5" Full-Range Driver is a high-quality driver designed to deliver exceptional sound quality across a wide frequency range. Featuring a 6.5" diaphragm and a 4 Ohm impedance, this driver provides an impressive frequency response of 70Hz-7kHz, ensuring clear and accurate sound reproduction across the entire audio spectrum.

The CMR160's solid build quality and advanced construction ensure that this driver can handle high volumes without distortion, making it perfect for use in a wide range of applications. Its compact and efficient design makes it perfect for use in small to medium-sized speakers, as well as in automotive and marine audio systems.

Whether you're a DIY audio enthusiast or a professional sound engineer, the Ciare CMR160 6.5" Full-Range Driver 4 Ohm is the perfect choice for any audio project that demands exceptional sound quality and clarity.

Product Details

BrandCiare
ModelCMR160
Part Number293-108
UPC848864073033
Unit of MeasureEach
Weight5.8

Product Specifications

Nominal Diameter6-1/2"
Bolt Circle Diameter6.14
Power Handling (RMS)80 Watts
Power Handling (MAX)200 Watts
Impedance4Ω
Frequency Response80 to 8,000Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)66Hz
DC Resistance (Re)3.55Ω
Voice Coil Inductance (Le)0.11mH
Mechanical Q (Qms)7.26
Electromagnetic Q (Qes)0.34
Total Q (Qts)0.32
Compliance Equivalent Volume (Vas)0.63ft³
Mechanical Compliance of Suspension (Cms)0.7mm/N
BL Product (BL)6.58T·m
Diaphragm Mass Inc. Airload (Mms)8.5g
Maximum Linear Excursion (Xmax)1.5mm
Surface Area of Cone (Sd)135cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter6.52"
Baffle Cutout Diameter5.59"
Depth3.15"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.055ft³
Sealed F3184.5Hz
Vented Volume0.1ft³
Vented F3140Hz
