  • Celestion CDX14-3040 Neodymium 1.4" Compression Driver 4-Bolt 75W

CLEARANCE Celestion CDX14-3040 Neodymium 1.4" Compression Driver 4-Bolt 75W

Celestion
Part #294-2154

CLEARANCE Celestion CDX14-3040 Neodymium 1.4" Compression Driver 4-Bolt 75W

Celestion
Part #294-2154
Model: CDX14-3040
Celestion's CDX14-3040 large format 1.4" compression driver uses a pure titanium 3" diaphragm driven by a compact but powerful neodymium magnet to produce premium high frequency response with excellent output capability. Using advanced FEA optimization on every aspect of this driver, Celestion refined the CDX14-3040 to ensure extremely low distortion, natural response, and amazing reliability.
Key Features
  • Lightweight one piece 3" diaphragm and surround provides accurate and dynamic response
  • Exceptionally powerful neodymium motor minimizes size and weight without sacrificing performance
  • Wide bandwidth capability and smooth response for an easy transition to midrange drivers
  • 106.5 dB sensitivity with 75 watt power handling allows incredibly output capability
  • Spring-loaded push-button connectors for quick, easy, and reliable wire connection
CLEARANCE $299.00
+ FREE SHIPPING
MSRP: $448.50
Save $149.50 (33%)
Bulk Pricing
Ships next business day. Details

Only 1 In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Celestion CDX14-3040 Neodymium 1.4" Compression Driver 4-Bolt 75W

Built to deliver low distortion high frequency response at incredible SPL, the Celestion CDX14-3040 1.4" titanium compression driver will provide outstanding performance, low distortion, and unmatched reliability. Celestion designed every component on this driver using Finite Element Analysis to ensure optimal output capability while minimizing distortion. For accurate response, the CDX14-3040 uses a non-resonant and rigid one-piece titanium diaphragm and surround assembly. The large 3" edgewound copper clad aluminum voice coil dissipates ample heat to handle up to 75 watts with negligible power compression. Driving the coil is an incredibly powerful neodymium motor allowing high efficiency and cuts size and weight. The CDX14-3040 continues Celestion tradition of developing high output drivers that deliver industry standard setting performance and reliability.

Specifications: • Power handling: 75 watts RMS (AES standard) • Throat size: 1.4" • Recommended min. crossover: 1,000 kHz, 12 dB/octave • VCdia: 3" • Impedance: 8 ohms • Frequency response: 500-18,000 Hz • Sensitivity: 106.5 dB 1W/1m • Mounting (flange): 4 x M6 holes on 4" PCD • Dimensions: 7" dia. x 2.7" depth • Net weight: 5 lbs.

Product Details

BrandCelestion
ModelCDX14-3040
Part Number294-2154
UPC848864066998
Unit of MeasureEach
Weight5.3

Product Specifications

Diaphragm MaterialTitanium
Exit Diameter1.4"
Mounting Type4-Bolt
Power Handling (RMS)75 Watts
Impedance

Specifications

Q&A

Reviews

Manuals & Resources
