BUYOUT ARA 6707018 5" x 7" Full-Range Paper Cone Speaker 6 Ohm

Read 1 Review or
Factory Buyouts
Part #299-4194

BUYOUT ARA 6707018 5" x 7" Full-Range Paper Cone Speaker 6 Ohm

Factory Buyouts
Part #299-4194
Model: 6707018
Read 1 Review or

The ARA 6707018 5" x 7" speaker uses a paper cone and surround to produce natural full-range response from 80 to 10,000 Hz. With a low moving mass and compliant suspension this driver has excellent efficiency, making it a great choice for producing high output from low power systems

Key Features
  • Natural paper cone minimizes cone resonance to provide smooth response
  • Raised pole piece improves flux distribution through the magnetic gap
  • Integrated dust cover helps protect the cone from foreign objects
  • Common size makes this driver an ideal replacement speaker
BUYOUT $3.88
Bulk Pricing
Quantity:Qty: 1-29 $3.88/ea
Quantity:Qty: 30-59 $3.45/ea
Quantity:Qty: 60+$3.30/ea
Ships next business day. Details

1084In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

ARA 6707018 5" x 7" Full-Range Paper Cone Speaker 6 Ohm

The ARA 6707018 5" x 7" speaker's common size makes it ideal for replacing blown or damaged drivers. Thanks to the lightweight paper cone, this driver has a sensitivity of 91 dB @ 2.83V/1M to deliver a surprising amount of output without requiring a lot of power. In addition, the integrated dust cover protects the cone from debris and foreign objects.

Note: Due to venting through the cone, the ARA 6707018 full-range is recommended for use in open back and free air designs only.

Product Details

BrandFactory Buyouts
Model6707018
Part Number299-4194
UPC848864073446
Unit of MeasureEach
Weight0.9

Product Specifications

Bolt Circle Diameter7.5
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance6Ω
Frequency Response80 to 10,000Hz
Sensitivity91dB 2.83V/1m
Voice Coil Diameter0.75"

Thiele-Small Parameters

Resonant Frequency (Fs)87Hz
DC Resistance (Re)5.6Ω
Voice Coil Inductance (Le)0.28mH
Mechanical Q (Qms)6.5
Electromagnetic Q (Qes)2.24
Total Q (Qts)1.67
Compliance Equivalent Volume (Vas)0.67ft³
Mechanical Compliance of Suspension (Cms)0.13mm/N
BL Product (BL)2.5T·m
Diaphragm Mass Inc. Airload (Mms)4.5g
Maximum Linear Excursion (Xmax)2mm
Surface Area of Cone (Sd)134cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialPaper
Voice Coil Wire MaterialAluminum
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter5" x 8.25"
Baffle Cutout Diameter4.5" x 6.75"
Depth2.25"
# Mounting Holes2

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.7ft³
Sealed F382Hz
