Yamaha RX-V4A 5.2-Channel Home Theater Receiver with MusicCast 80 Watts per Channel

1 Question, 2 Answers or
Yamaha
Part #312-549

Yamaha RX-V4A 5.2-Channel Home Theater Receiver with MusicCast 80 Watts per Channel

Yamaha
Part #312-549
Model: RX-V4ABL
1 Question, 2 Answers or
Bring the theater home with the Yamaha RX-V4ABL 5.2-channel 80 Watt AV receiver. Creating a powerful and advanced home theater experience with the latest in video processing and Dolby Digital Plus, DTS-HD Master Audio, app control, wireless streaming and more, the RX-4VBL animates your entertainment to life.
Key Features
  • 5.2-channel 80 Watt surround sound with Dolby Digital Plus and DTS-HD for immersive home theater experience
  • 4K/120Hz and 8K/60Hz HDMI compatibility with HDCP 2.3 and eARC (4 in/1 out) provides highest quality viewing
  • Supports enhanced media and gaming formats such as ALLM, VRR, QFT, QMS
  • Wi-Fi, AirPlay 2, Spotify Connect, MusicCast, and Voice Control give you control over streaming options
  • YPAO automatic room calibration
Your Price: $399.95
+ FREE SHIPPING
MSRP: $499.95
Save $100.00 (20%)
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Yamaha RX-V4A 5.2-Channel Home Theater Receiver with MusicCast 80 Watts per Channel

Unparalleled Sound

CINEMA DSP 3D

This unique Yamaha proprietary sound field creation technology was created by combining measured sound field data with digital signal processing. Yamaha collected sound field data from famous concert halls and music clubs around the world, utilizing its wealth of experience in the fields of concert hall design, public address and mixing. By digitizing this vast trove of information and incorporating it into dedicated LSI devices, it effectively reproduces the spaces of concert halls and music clubs in your home. Immerse yourself in the astounding realism of your movies and enter a world of profound theater sound.

Compressed Music Enhancer

When music is encoded into a digitally compressed format like MP3, the frequency response suffers. The Yamaha Compressed Music Enhancer employs sophisticated digital signal processing using exclusive algorithms to restore what was lost, so the music always sounds the way it should.

Movies And Games Like Never Before

HDR and HDR10+

HDR (high dynamic range) video provides incredible contrast, smooth tone and rich, bright colors—giving you full, high-definition enjoyment with an exceptionally realistic and natural picture quality.

HDR10+ greatly improves dynamic range (the ratio of light to dark) of video content on a scene-by-scene (or even frame-by-frame) basis. Also, using frame-by-frame metadata, it improves the scene characteristics between bright and dark so that important detail can remain. This enables displays to reproduce images more realistically, adhering to the creator's intent.

Note: HDR10+ is available via a future firmware update

4K/120Hz, 8K/60Hz and 4K/60Hz

Supports end-to-end 8K/4K resolutions and higher refresh rate solutions with a single upgraded cable for seamless integration within the HDMI eco-system. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. 4K/120Hz enables ultra-fast motion UHD images to be crisp and razor sharp; allowing sports, action movies, high-performance gaming and VR to benefit significantly.

Note: 4K/120Hz and 8K/60Hz are available via a future firmware update

Enhanced Media and Gaming (ALLM, VRR, QMS, QFT)

Enhanced media and gaming features ensure an added level of smooth and seamless motion and transitions for gaming, movies and video. They include: Auto Low Latency Mode (ALLM), which enables the ideal latency setting to automatically be set allowing for smooth, lag-free and uninterrupted viewing and interactivity; Variable Refresh Rate (VRR) reduces or eliminates lag, stutter and frame tearing for more fluid and detailed gameplay; Quick Media Switching (QMS) for movies and video eliminates the delay that can result in blank frames before content is displayed; and Quick Frame Transport (QFT), which reduces latency for smoother, no-lag gaming and real-time interactive virtual reality.

Note: These features are available via a future firmware update

Simple To Set Up, Simple To Use

AV Setup Guide App for Initial Setup

No worries, no confusion. Use this special app to receive expert set up assistance for your AV receiver and source devices. It even guides you through various other settings such as speaker connections, TV and source device connections and power amplifier assignments.

Learn more about AV Setup Guide App

Simple and Easy with the MusicCast App

Use your smartphone or tablet together with the MusicCast app to operate the AV receiver and change settings quickly and easily. The app offers the same functions as a remote control for all your MusicCast-compatible devices as well as full multi-room audio controls.

Learn more about MusicCast

Voice Control (Alexa, Google Assistant, and Siri)

Easily works with Alexa, Google Assistant and Siri (via Airplay 2), so your AV receiver is always at your command and your whole home can come alive.

Note: A third party device is required to initiate voice commands

Made For Your Room

YPAO™ automatic room calibration with R.S.C. and Multi-Point

YPAO (Yamaha Parametric room Acoustic Optimizer) analyzes your room acoustics, measures speaker characteristics and adjusts unwanted reflected sounds to optimize every channel of your home theater. R.S.C. (Reflected Sound Control) analyzes room acoustics and measures various speaker characteristics, then calibrates audio parameters to achieve optimum sound at any of eight listening positions.

Simply by placing the supplied microphone at your listening position and switching YPAO on, the system is automatically calibrated ensuring your home theater room has the best sound.

Made For Your Room

MusicCast Surround

Combine this AV receiver with the MusicCast 50 or two MusicCast 20 wireless streaming speakers and enjoy MusicCast Surround, creating a 5.1-channel home theater with wireless surround sound. What’s more, you get stunningly realistic sound with a clean, clutter-free setup. Easily turn your living room into a home theater where you can fully enjoy movies and music.

SCENE Buttons with the Ability to Preset Songs and Stations

Easily program up to 8 different preset scenarios using 4 SCENE buttons. You can preset them for different inputs, as well as a sound field program, Music Enhancer, HDMI output and more. The inputs can be set to specific sources, such as an FM or Internet radio station, a station on a streaming service, a USB device or a song on a PC or NAS (Network-attached Storage). Once you’ve set the buttons, simply press one on the main unit or the remote control to power on the receiver and hear your desired music. The buttons can be re-set at any time.

Streaming, Apps, and More

Stream it All

Explore a world of music with music streaming services built-in. Synchronizing your playlists and tracks from your smart phone or computer to the AV receiver, music streaming services make it easy to either listen to your favorites or discover new music.

Multi-room Audio - MusicCast

Imagine sharing all the music you love throughout the home – no matter the format. From your favorite vinyl to AirPlay®, Bluetooth® to music streaming services and even sound from your TV, MusicCast has it covered.

Additionally, all MusicCast products are designed with sound quality at the front of mind. High-res formats including Apple Lossless (ALAC) up to 96 kHz, WAV, FLAC and AIFF up to 384 kHz are supported.

AirPlay 2

Hey Siri. Play music in the kitchen and living room.

AirPlay 2 adds the ability to stream Apple Music and other streaming services to multiple MusicCast devices throughout your home. Easily control it from your iPhone or iPad, link it with a HomePod, or simply utilize voice control and ask Siri for an assist.

eARC

Unlock the full potential of your 4K content. Enhanced Audio Return Channel (also known as eARC) is the next generation of ARC – available in the industry-leading AV receivers from Yamaha.

eARC delivers full-resolution, multi-channel audio formats such as Dolby TrueHD and DTS-HD through your existing HDMI connection, giving you the most realistic surround sound experience for immersing yourself in your favorite movies and moments.

Specifications:


• Channels: 5.2
• Rated output power (20-20,000 Hz, 2 ch driven): 80 W (6 ohms, 0.06% THD)
• File format: MP3 / WMA / MPEG-4 AAC: up to 48 kHz/16-bit, ALAC: up to 96 kHz/24-bit, FLAC: up to 192 kHz/24-bit, WAV / AIFF: up to 192 kHz/32-bit, DSD: up to 11.2 MHz
• Surround sound processing: Cinema DSP, Virtual Presence Speaker, SILENT Cinema/Virtual Cinema DSP, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio
• Audio features: Pure Direct, Compressed Music Enhancer, YPAO, Adaptive DRC, Bi-amp Capability, Audio Delay (0-500 ms), DA Converter (384 kHz/32-bit BB PCM5102A
• Video features: HDMI eARC, HDMI Audio Return Channel, HDMI Pass-through (4K/120, 8K/60, 4K/60 - via future firmware update), HDMI Upscale (up to 4K), HRD 10+ (future firmware update), VRR/ALLM/QMS/QFT (future firmware update)
• Wireless connections: MusicCast Surround, Wi-Fi (2.4/5 GHz), AirPlay2, Bluetooth (SBC, AAC)
• Analog audio connections: 3/0, headphone output
• Digital audio connections: Optical (1/0), Coaxial (1/0),
• Pre-out: 0.2-ch
• HDMI in/out: 4/1 (HDR/Dolby Vision/HLG/BT.2020)
• Connections: HDMI CEC, USB, Network Port
• User interface: On-screen GUI, SCENE (4 sets), app control, remote control
• Standby power consumption: 0.1W
• Power modes: Auto power standby, ECO mode
• Weight: 19.4 lbs.
• Dimensions: 17-1/8" W x 6-3/4" H x 14-7/8" D (with antenna up:17-1/8" W x 9-5/8" H x 14-7/8" D)

Product Details

BrandYamaha
ModelRX-V4ABL
Part Number312-549
UPC027108958927
Unit of MeasureEach
Weight22.6

Product Specifications

Power Output Per Channel80Watts
Receiver Type5.1 Channel Surround
