WBT's Crimping method is the preferred technique because it produces a physically and chemically optimum contact point with low transition resistance, which ensures pure signal transmission. For the procedure itself one must first strip the cable and insert it into the crimp sleeve. Insert the wire and sleeve into the proper slot on the crimper, and squeeze. The crimp and unique crescent shape force the wire to flow together, thus creating the illusion of a single strand of wire. Then trim the sleeve to the desired length to fit the application. Loosen the Torx™ screws on connector inset the cable and tighten down, one screw for the conductor and the other screw for the strain relief. The technique is easy to apply, and easy to fit and re-fit in WBT connectors.
Note: Each WBT Midline binding post requires an additional M4x7mm T-6 Torx Screw if installing without solder.
Product Details | |
|---|---|
| Brand | WBT |
| Model | 0765W |
| Part Number | 093-563 |
| UPC | 726441935632 |
| Unit of Measure | Each |
| Weight | 0.05 |
Product Specifications | |
|---|---|
| Contact Plating | Gold |
| Style / Type | Single |
