  • Visaton SL87 FE-8 Ohm 3.4" Full Range Speaker 8 Ohm

Visaton SL87 FE-8 Ohm 3.4" Full Range Speaker 8 Ohm

Visaton
Part #292-614

Visaton SL87 FE-8 Ohm 3.4" Full Range Speaker 8 Ohm

Visaton
Part #292-614
Model: SL87 FE
For building your own small high fidelity speaker, look no further than Visaton's SL87 FE. It also makes a great driver for column line arrays.
Key Features
  • Rubber surround and spun plastic cone for neutral sound
  • IP64-rated for protection against dust and water
  • High power ferrite motor
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $17.75
MSRP: $23.99
Save $6.24 (26%)
Bulk Pricing
Quantity:Qty: 1-9 $17.75/ea
Quantity:Qty: 10-24 $17.22/ea
Quantity:Qty: 25+$16.49/ea
Order in the next 9 hr 54 min to ship today. Details

10In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton SL87 FE-8 Ohm 3.4" Full Range Speaker 8 Ohm

Visaton designed the 3.4" SL87 FE speaker for flat frequency response from 100 to 15,000 Hz for use in small high fidelity speaker systems and for thin, column array speakers for personal professional audio use. This driver is also weather resistant for permanent installations in humid environments and for outdoor use.

A spun plastic cone is combined with a rubber surround for self-damped output without the need of a crossover, while offering IP64 protection against dust ingress and splashed water when installed in a proper enclosure. The large ferrite magnet keeps Qts down to respectable rating of 0.65 for true fidelity and a small enclosure requirement, while increasing sensitivity to 87 dB (1 watt/1 meter).

Product Details

BrandVisaton
ModelSL87 FE
Part Number292-614
Unit of MeasureEach
Weight1.1

Product Specifications

Nominal Diameter3-1/2"
Bolt Circle Diameter3.86
Power Handling (RMS)10 Watts
Power Handling (MAX)15 Watts
Impedance8Ω
Frequency Response75 to 18,000Hz
Sensitivity87dB 2.83V/1m
Voice Coil Diameter0.79"

Thiele-Small Parameters

Resonant Frequency (Fs)120Hz
DC Resistance (Re)7.2Ω
Mechanical Q (Qms)3.3
Electromagnetic Q (Qes)0.82
Total Q (Qts)0.65
Compliance Equivalent Volume (Vas)0.05ft³
BL Product (BL)3.95T·m
Diaphragm Mass Inc. Airload (Mms)2.4g
Maximum Linear Excursion (Xmax)1.75mm
Surface Area of Cone (Sd)37.3cm²

Materials of Construction

Cone MaterialPoly
Surround MaterialRubber
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3.32" across the flats, diagonally 4.70"
Baffle Cutout Diameter3.15"
Depth1.93"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.08ft³
Sealed F3147.5Hz
Vented Volume0.08ft³
Vented F398.6Hz
