Visaton SC 5.9 2" x 3.5" Shielded Full-Range Driver 8 Ohm

Visaton
Part #292-551

Visaton SC 5.9 2" x 3.5" Shielded Full-Range Driver 8 Ohm

Visaton
Part #292-551
Model: SC 5.9
Visaton's SC 5.9 8 ohm driver is an economical full-range driver that features a narrow oval shape, shielded motor, water resistant paper cone, front gasket, and steel frame.
Key Features
  • Water resistant paper cone with foam surround for linear frequency response
  • Rugged stamped steel frame with front mounted gasket
  • Shielded high-energy ferrite magnet assembly
  • Common size used in many flat screen televisions
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $9.43
MSRP: $12.99
Save $3.56 (27%)
Bulk Pricing
Quantity:Qty: 1-9 $9.43/ea
Quantity:Qty: 10-24 $9.15/ea
Quantity:Qty: 25+$8.76/ea
Order in the next 15 hr 13 min to ship today. Details

133In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton SC 5.9 2" x 3.5" Shielded Full-Range Driver 8 Ohm

Engineers, designers, and integrators will benefit from how effortlessly Visaton's SC 5.9 8 ohm full-range speaker fits into modern audio applications where small size requirements dictate speaker design.

The SC 5.9 features an oval design that maximizes cone area for high output, while fitting into narrow spaces. A water resistant paper cone and foam surround combine to maintain efficiency without sacrificing frequency response.

Product Details

BrandVisaton
ModelSC 5.9
Part Number292-551
Unit of MeasureEach
Weight0.5

Product Specifications

Nominal Diameter2 x 3"
Power Handling (RMS)10 Watts
Power Handling (MAX)15 Watts
Impedance8Ω
Frequency Response130 to 20,000Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter0.55"

Thiele-Small Parameters

Resonant Frequency (Fs)193Hz
DC Resistance (Re)7Ω
Voice Coil Inductance (Le)0.4mH
Mechanical Q (Qms)7.52
Electromagnetic Q (Qes)1.5
Total Q (Qts)1.25
Compliance Equivalent Volume (Vas)0.014ft³
Mechanical Compliance of Suspension (Cms)0.453mm/N
BL Product (BL)2.5T·m
Diaphragm Mass Inc. Airload (Mms)1.5g
Maximum Linear Excursion (Xmax)1.5mm
Surface Area of Cone (Sd)24.9cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialFoam
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter2" x 3.5"
Baffle Cutout Diameter1.78" x 2.34"
Depth1.69"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.015ft³
Sealed F3191Hz
