Visaton FR 58-4 2.3" Full Range Speaker 4 Ohm

Visaton
Part #292-634

Visaton FR 58-4 2.3" Full Range Speaker 4 Ohm

Visaton
Part #292-634
Model: FR 58 - 4
The FR 58 2.3" full-range driver uses a coated paper cone and rubber surround to achieve an IP65 rating, making this driver suitable for outdoor use. Perfect for use in portable speakers that may be exposed to the elements.
Key Features
  • IP65 rating allows this driver to be used in outdoor speakers
  • Naturally damped paper cone for smooth response
  • Extremely flat response from 200 to 20,000 Hz
  • Perfect driver for use in portable Bluetooth speakers.
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $8.88
MSRP: $11.99
Save $3.11 (26%)
Bulk Pricing
Quantity:Qty: 1-9 $8.88/ea
Quantity:Qty: 10-24 $8.61/ea
Quantity:Qty: 25+$8.24/ea
Ships next business day. Details

74In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Visaton FR 58-4 2.3" Full Range Speaker 4 Ohm

Visaton's FR 58 full-range driver is a great choice for use in outdoor speakers that might be directly exposed to rain. When used in a suitable sealed enclosure this driver has an IP65 rating (meaning it can withstand direct exposure to water and dust). With a remarkably smooth frequency response, this is an ideal driver for use in hi-fi outdoor speaker systems.

Product Details

BrandVisaton
ModelFR 58 - 4
Part Number292-634
Unit of MeasureEach
Weight0.33

Product Specifications

Nominal Diameter2-1/4"
Bolt Circle Diameter2.5
Power Handling (RMS)10 Watts
Power Handling (MAX)12 Watts
Impedance
Frequency Response120 to 20,000Hz
Sensitivity81dB 2.83V/1m
Voice Coil Diameter0.55"

Thiele-Small Parameters

Resonant Frequency (Fs)190Hz
Maximum Linear Excursion (Xmax)0.55mm

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialRubber
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside DiameterSquare: 2.3"
Baffle Cutout Diameter2"
Depth1.1"
# Mounting Holes4
