Visaton DT94-4 0.8" Polycarbonate Dome Tweeter 4 Ohm

Visaton
Part #292-554

Visaton DT94-4 0.8" Polycarbonate Dome Tweeter 4 Ohm

Visaton
Part #292-554
Model: DT94 - 4

The 9003 DT94 4 ohm, 20 mm polycarbonate dome tweeter from Visaton is designed for high power handling and features smooth frequency response.

Key Features
  • 1.2 kHz to 22 kHz frequency response
  • Ferrofluid-cooled 4 ohm voice coil
  • 93 dB sensitivity at 2.83v/1meter
  • High power handling
  • Wide dispersion pattern
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $30.68
MSRP: $39.99
Save $9.31 (23%)
Bulk Pricing
Quantity:Qty: 1-9 $30.68/ea
Quantity:Qty: 10-24 $29.76/ea
Quantity:Qty: 25+$28.49/ea

Out of Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton DT94-4 0.8" Polycarbonate Dome Tweeter 4 Ohm

Visaton's 9003 DT94 4 ohm, 20 mm polycarbonate HiFi dome tweeter features smooth frequency response, high power handling (due to the ferrofluid cooled voice coil), and great dispersion characteristics that are a result of the integrated phase plug.

Product Details

BrandVisaton
ModelDT94 - 4
Part Number292-554
Unit of MeasureEach
Weight0.603

Product Specifications

Cone / Dome Diameter0.75"
Cutout Diameter2.52
Tweeter TypePoly / Mylar Dome
Power Handling (RMS)50 Watts
Impedance4Ω
Frequency Response1,200 to 22,000Hz
Sensitivity93dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)1900Hz
DC Resistance (Re)3.1Ω
Voice Coil Inductance (Le)0.09mH
Mechanical Q (Qms)3
Electromagnetic Q (Qes)0.6
Total Q (Qts)0.5

Mounting Information

Overall Outside Diameter3.70"
Depth0.75"
