Visaton B 80 3.3" Full-Range Driver 8 Ohm

Visaton
Part #292-660

Visaton B 80 3.3" Full-Range Driver 8 Ohm

Visaton
Part #292-660
Model: B80

The smooth response, excellent off axis response, and high power handling of the Viaston B 80 full-range driver makes it an extremely flexible driver that is suitable for use in a compact full-range system or even a midrange in larger 3-way systems.

Key Features
  • Coated paper cone delivers a natural response free of unwanted resonances
  • The cast aluminum basket provides extensive venting and a rigid frame
  • An aluminum phase plug improves off axis response and helps to keep inductance linear
  • Low weight and high motor force thanks to the powerful Neodymium magnet
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $84.14
MSRP: $109.99
Save $25.85 (24%)
Bulk Pricing
Quantity:Qty: 1-9 $84.14/ea
Quantity:Qty: 10-24 $81.63/ea
Quantity:Qty: 25+$78.13/ea
Ships next business day. Details

7In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton B 80 3.3" Full-Range Driver 8 Ohm

Viaston’s B 80 3.3" full-range driver has been engineered to provide extremely smooth response and minimal distortion. The well damped coated paper cone with aluminum phase plug provides almost ideal off axis response up to 4,000 Hz. A powerful neodymium motor allows the B 80 to deliver impressive efficiency for its size and keeps distortion to a minimum. With a minimalistic cast aluminum frame, the back side of the cone has ample breathing room with virtually zero reflection. Finally, extensive under spider venting helps to keep the voice coil cool while minimizing compression under demanding situations. With all of these features, Visaton’s B 80 3.3” full-range driver is an excellent choice for everything from a portable Bluetooth speaker to midrange duty in a large 3-way tower.

Product Details

BrandVisaton
ModelB80
Part Number292-660
Unit of MeasureEach
Weight0.85

Product Specifications

Nominal Diameter4"
Bolt Circle Diameter3.74
Power Handling (RMS)30 Watts
Power Handling (MAX)50 Watts
Impedance8Ω
Frequency Response80 to 20,000Hz
Sensitivity85dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)110Hz
DC Resistance (Re)6.6Ω
Mechanical Q (Qms)6.53
Electromagnetic Q (Qes)0.69
Total Q (Qts)0.63
Compliance Equivalent Volume (Vas)0.0636ft³
Mechanical Compliance of Suspension (Cms)0.748mm/N
BL Product (BL)4.15T·m
Diaphragm Mass Inc. Airload (Mms)2.8g
Maximum Linear Excursion (Xmax)2.2mm
Surface Area of Cone (Sd)41.17cm²

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialRubber
Basket / Frame MaterialCast Aluminum
Magnet MaterialAlNiCo

Mounting Information

Overall Outside Diameter4.11"
Baffle Cutout Diameter3.42"
Depth1.94"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.1ft³
Sealed F3138.9Hz
Vented Volume0.1ft³
Vented F391.2Hz
