Tang Band W8-1808 8" Neodymium Full Range Driver

Tang Band
Part #264-894

Tang Band W8-1808 8" Neodymium Full Range Driver

Tang Band
Part #264-894
Model: W8-1808
The W8-1808 neo full range driver incorporates a higher Qts for large or open enclosures. An underhung voice coil and carefully balanced paper cone contribute to smooth response with exceptionally low distortion.
Key Features
  • Underhung 1-1/2" voice coil
  • Copper plated aluminum phase plug
  • Secondary "whizzer" cone improves HF response
  • Optimized for larger single-driver enclosures
  • Cast frame and neodymium magnet structure
  • 5 mm Xmax
Similar items that may interest you:
See all items in Midrange / Midbass Drivers & Full-Range Speakers
Your Price: $359.98
+ FREE SHIPPING
MSRP: $467.99
Save $108.01 (23%)
Bulk Pricing
Quantity:Qty: 1-3 $359.98/ea
Quantity:Qty: 4-9 $341.98/ea
Quantity:Qty: 10+$323.98/ea
Order in the next 5 hr 14 min to ship today. Details

15In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Tang Band W8-1808 8" Neodymium Full Range Driver

The W8-1808 neo full range driver incorporates a higher Qts for large or open enclosures. An underhung voice coil and carefully balanced paper cone contribute to smooth response with exceptionally low distortion. Other features include a copper plated aluminum phase plug, die cast frame, and treated cloth surround. An ideal driver for single-ended tube amp systems.

Product Details

BrandTang Band
ModelW8-1808
Part Number264-894
UPC844632079047
Unit of MeasureEach
Weight7.45

Product Specifications

Nominal Diameter8"
Power Handling (RMS)30 Watts
Power Handling (MAX)60 Watts
Impedance8Ω
Frequency Response45 to 20,000Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)45Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)0.04mH
Mechanical Q (Qms)1.33
Electromagnetic Q (Qes)0.66
Total Q (Qts)0.44
Compliance Equivalent Volume (Vas)3.11ft³
Mechanical Compliance of Suspension (Cms)1.28mm/N
BL Product (BL)5.28T·m
Diaphragm Mass Inc. Airload (Mms)9.43g
Maximum Linear Excursion (Xmax)5mm
Surface Area of Cone (Sd)220cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter8.81"
Baffle Cutout Diameter7.48"
Depth4.53"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.68ft³
Sealed F388.4Hz
Vented Volume1.5ft³
Vented F359Hz
