Tang Band W2-2136S 2" Aluminum Full Range Neodymium Driver

Tang Band
Part #264-839

Tang Band W2-2136S 2" Aluminum Full Range Neodymium Driver

Tang Band
Part #264-839
Model: W2-2136S
Tang Band, one of the leaders in small full range technology, presents the W2-2136S 2" full range driver. This is a perfect candidate for use in portable speakers, computer speakers, or even TV sound bars.
Key Features
  • Smooth response down to 120 Hz for easy transition to a subwoofer
  • Excellent choice for use in line arrays and modern mini-speaker designs
  • Unique Santoprene surround provides damping for the aluminum cone
  • Powerful neodymium motor keeps size and weight to a minimum
Your Price: $45.00
MSRP: $67.99
Save $22.99 (34%)
Bulk Pricing
Order in the next 0 hr 19 min to ship today. Details

281In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Tang Band W2-2136S 2" Aluminum Full Range Neodymium Driver

Speakers today are becoming smaller and smaller and the need for small drivers is constantly increasing. Tang Band has been one of the leaders in small driver technology and now they bring you the 4 ohm W2-2136S 2" aluminum cone full range. At only 57 mm square, this driver will fit almost anywhere you can imagine. The incredibly smooth response from 120 to 15,000 Hz makes it excellent for use in portable Bluetooth speakers and small sound bars. When teamed up with a subwoofer the W2-2136S delivers superb performance in portable speakers or even an ultra-small satellite.

Product Details

BrandTang Band
ModelW2-2136S
Part Number264-839
UPC848864023724
Unit of MeasureEach
Weight0.35

Product Specifications

Nominal Diameter2"
Bolt Circle Diameter2.55
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance4Ω
Frequency Response120 to 15,000Hz
Sensitivity83dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)120Hz
DC Resistance (Re)3.4Ω
Voice Coil Inductance (Le)0.03mH
Mechanical Q (Qms)1.59
Electromagnetic Q (Qes)0.39
Total Q (Qts)0.31
Compliance Equivalent Volume (Vas)0.0091ft³
Mechanical Compliance of Suspension (Cms)0.801mm/N
BL Product (BL)3.71T·m
Maximum Linear Excursion (Xmax)2mm
Surface Area of Cone (Sd)15cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialSantoprene®
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialPolymer
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter2.27"
Baffle Cutout Diameter2.16"
Depth1.36"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Vented Volume0.02ft³
Vented F3107.8Hz
