Peerless by Tymphany XT25BG60-04 1" Dual Ring Radiator Tweeter

Peerless by Tymphany XT25BG60-04 1" Dual Ring Radiator Tweeter

Peerless by Tymphany
Part #264-1012
The Tymphany XT25BG60-04 features a patented dual concentric diaphragm and a unique waveguide center plug that provide an excellent on- and off-axis response.
Key Features
  • Outstanding performance in 2-way systems
  • Dual ring radiator diaphragm (patented)
  • Waveguide center plug (patented)
  • Copper-clad aluminum VC wire
  • Double magnet system
  • Flat response well beyond 20 kHz
  • Low distortion
Similar items that may interest you:
Your Price: $30.19
+ FREE SHIPPING
MSRP: $51.99
Save $21.80 (42%)
Bulk Pricing
Quantity:Qty: 1000+$30.19/ea

Back-Ordered

Advertised price subject to change due to tariff uncertainty
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details

Overview

Peerless by Tymphany XT25BG60-04 1" Dual Ring Radiator Tweeter

The Tymphany XT25BG60-04 features a patented dual concentric diaphragm and a unique waveguide center plug that provide an excellent on- and off-axis response. The XT25-type tweeter is acclaimed for its very natural sound with an extremely smooth frequency response extending well beyond the human hearing range. The dual chamber design and absence of ferrofluid results in a low resonance frequency.

Product Details

BrandPeerless by Tymphany
ModelXT25BG60-04
Part Number264-1012
UPC844632083679
Unit of MeasureEach
Weight1.7

Product Specifications

Cone / Dome Diameter1"
Cutout Diameter2.83
Tweeter TypeSoft Dome
Power Handling (RMS)90 Watts
Impedance
Frequency Response1,500 to 20,000Hz
Sensitivity92.3dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)589.1Hz
DC Resistance (Re)
Voice Coil Inductance (Le)0.01mH
Mechanical Q (Qms)1.31
Electromagnetic Q (Qes)0.43
Total Q (Qts)0.32

Mounting Information

Overall Outside Diameter4.09"
Depth2.17"
