CLEARANCE Peerless GBS-250F38CP01-04 10" Paper Cone Woofer 4 Ohm

Peerless by Tymphany
Part #264-1492

CLEARANCE Peerless GBS-250F38CP01-04 10" Paper Cone Woofer 4 Ohm

Peerless by Tymphany
Part #264-1492
The low profile GBS-250F38CP01-04 from Peerless can deliver high performance bass reproduction from the shallowest designs. With only 1.5" mounting depth and capable of high excursion this unique driver can mount where no other true subwoofers can.
Key Features
  • Just over 1.5" mounting depth without sacrificing quality or performance
  • Amazing excursion capability for powerful bass response from shallow enclosures
  • Optimized ferrite motor design allows impressive efficiency from a low profile driver
  • Excellent choice for car audio systems where space is at a premium
60 Day No Hassle Return Policy

Overview

Peerless GBS-250F38CP01-04 10" Paper Cone Woofer 4 Ohm

The Peerless GBS-250F38CP01-04 10" 4 ohm subwoofer provides a very slim profile that is capable of large excursion. A unique treater paper dome helps to provide room to move the motor assembly and spider further forward without sacrificing excursion or efficiency, which is an issue with many low profile driver designs. A highly optimized ferrite motor and unique suspension layout combine to give a cost effective solution in a previously unavailable package.

Product Details

BrandPeerless by Tymphany
ModelGBS-250F38CP01-04
Part Number264-1492
UPC848864045078
Unit of MeasureEach
Weight8.2

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.88
Power Handling (RMS)200 Watts
Power Handling (MAX)400 Watts
Impedance4Ω
Frequency Response50 to 2,000Hz
Sensitivity85.8dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)37.69Hz
DC Resistance (Re)3.45Ω
Voice Coil Inductance (Le)2.36mH
Mechanical Q (Qms)5.62
Electromagnetic Q (Qes)0.49
Total Q (Qts)0.45
Compliance Equivalent Volume (Vas)0.84ft³
Mechanical Compliance of Suspension (Cms)0.157mm/N
BL Product (BL)21.45T·m
Maximum Linear Excursion (Xmax)6mm
Surface Area of Cone (Sd)314.2cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.4"
Baffle Cutout Diameter8.98"
Depth2.9"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.3ft³
Sealed F372.1Hz
Vented Volume0.96ft³
Vented F339.5Hz
