  • Peerless by Tymphany 830667 8" Paper Cone SLS Subwoofer

Peerless by Tymphany 830667 8" Paper Cone SLS Subwoofer

Peerless by Tymphany
Part #264-1102

Peerless by Tymphany 830667 8" Paper Cone SLS Subwoofer

Peerless by Tymphany
Part #264-1102
Model: SLS-P830667
The Peerless SLS Series combines high quality performance with an affordable design.
Key Features
  • Premium sculpted stamped steel chassis
  • Coated paper cone with rubber edge
  • Shorting ring in magnet system
Your Price: $52.30
+ FREE SHIPPING
MSRP: $88.99
Save $36.69 (41%)
Bulk Pricing
Quantity:Qty: 1-5 $52.30/ea
Quantity:Qty: 6+$49.69/ea
Order in the next 1 hr 27 min to ship today. Details

In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Peerless by Tymphany 830667 8" Paper Cone SLS Subwoofer

The Peerless SLS Series combines high quality performance with an affordable design. The SLS drivers are ideal for use in systems with high power handling requirements, and are a logical choice for use with the SDS line of transducers.

Product Details

BrandPeerless by Tymphany
ModelSLS-P830667
Part Number264-1102
UPC844632084126
Unit of MeasureEach
Weight5.95

Product Specifications

Nominal Diameter8"
Power Handling (RMS)110 Watts
Power Handling (MAX)220 Watts
Impedance8Ω
Frequency Response36.5 to 2,000Hz
Sensitivity87.2dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)42Hz
DC Resistance (Re)5.5Ω
Voice Coil Inductance (Le)0.78mH
Mechanical Q (Qms)5.7
Electromagnetic Q (Qes)0.75
Total Q (Qts)0.66
Compliance Equivalent Volume (Vas)0.93ft³
Mechanical Compliance of Suspension (Cms)0.41mm/N
BL Product (BL)8.26T·m
Diaphragm Mass Inc. Airload (Mms)34.78g
Maximum Linear Excursion (Xmax)8.41mm
Surface Area of Cone (Sd)213.8cm²

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialRubber
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.44"
Baffle Cutout Diameter6.97"
Depth4.39"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1ft³
Sealed F352.2Hz
Vented Volume1.5ft³
Vented F331.2Hz
