PRV Audio D4500Ph 2" Phenolic Compression Driver 4-Bolt

PRV Audio
Part #294-3242

PRV Audio D4500Ph 2" Phenolic Compression Driver 4-Bolt

PRV Audio
Part #294-3242
PRV Audio's D4500Ph Trio series 2" midrange compression driver delivers the powerful combination of high efficiency, incredible power handling, and natural response. The 4" damped phenolic diaphragm produces a frequency response of 450 to 6,000 Hz making this driver ideal for reproducing the important vocal range with enough SPL to cut through the most powerful subwoofer.
Key Features
  • Damped phenolic diaphragm minimizes unwanted peaks for smooth response
  • 250 watts RMS and 108 dB efficiency to provide unbelievable output capability
  • 450 to 6,000 Hz frequency response to effortlessly cover the majority of the vocal range
  • Standard 4 bolt mount to easily install on most 2" throat horns
Your Price: $209.91
+ FREE SHIPPING
MSRP: $262.39
Save $52.48 (20%)
Bulk Pricing

Back-Ordered

Estimated back in stock 5/10/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio D4500Ph 2" Phenolic Compression Driver 4-Bolt

PRV Audio's D4500Ph 2" exit Trio series compression driver will provide high output midrange response with low distortion to reproduce the all-important vocal range with the authority and clarity even when driven to the highest output. Its light-weight 4" diameter CCA wire voice coil is wound on a high temperature Kapton former to reliably handle up to 100 watts RMS for extended periods (when used with the recommended 600 Hz, 12 dB/octave high pass crossover). The coil and powerful ferrite magnet drive a 4" phenolic diaphragm that minimizes unwanted resonances for smooth and natural response from 450 to 6,000 Hz. For use in the highest SPL sound systems, the formidable D4500Ph has the ability to deliver true concert level with low distortion and smooth response.

Specifications: • Power handling: 250 watts RMS, 500 watts peak (with 600 Hz, 12dB/octave high pass crossover) • Impedance: 8 ohms • Frequency response: 450-6,000 Hz • Sensitivity: 108 dB 2.83V/1m • Dimensions: 8.66" dia. x 3.66" depth.

Product Details

BrandPRV Audio
ModelD4500Ph
Part Number294-3242
UPC619620088253
Unit of MeasureEach
Weight18.55

Product Specifications

Diaphragm MaterialPhenolic
Exit Diameter2"
Mounting Type4-Bolt
Power Handling (RMS)250 Watts
Impedance8Ω
