PRV Audio 8MR500-4 BULLET 8" Midrange Speaker 4 Ohm

PRV Audio
Part #294-3143

PRV Audio 8MR500-4 BULLET 8" Midrange Speaker 4 Ohm

PRV Audio
Part #294-3143
Model: 8MR500-4 BULLET
Continuing PRV Audio's "pro audio on wheels" concept, the 8MR500-4 BULLET 8" midrange is built to deliver the same performance as a professional loudspeaker. Featuring an aluminum phase plug for improved high frequency response, this driver is able to give high levels of output from your custom door or rear deck.
Key Features
  • Extremely wide frequency response from 95 to 20,000 Hz for smooth midrange output
  • 95 dB efficient and 250 watt RMS power handling for incredible output capability
  • Aluminum phase plug improved high frequency response on and off-axis
  • Powerful motor and low moving mass to provide incredible dynamics and detail
Your Price: $54.91
MSRP: $68.64
Save $13.73 (20%)
Bulk Pricing
Ships next business day. Details

16In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 8MR500-4 BULLET 8" Midrange Speaker 4 Ohm

The 8MR400-4 BULLET 8" midrange speaker uses a "bullet" phase plug made from pure aluminum to lower inductance and act as a heat sink cooling system for the voice coil. Machined to perfection for even sound dissipation the phase plug also improves off-axis frequency response. Beyond good looks, this cone is extremely light, providing excellent damping to keep an incredibly natural yet accurate sound with incredible efficiency.

A triple roll cloth surround, combined with an optimized fiber pressed paper cone, ensure the speaker’s frequency response is smooth and extends to high range making an easy transition to a super tweeter. The suspension design of the 8MR500-4 BULLET features a single layer spider – which connects to the coil former with premium stitched lead wires. The cone is driven by a copper-clad aluminum wire voice coil providing high efficiency and excellent power handling.

This driver is constructed of high-performance characteristics and high-quality components to provide exceptional clarity, detail, and dynamic sound. You can expect outstanding sound stage quality and realistic sound reproduction for a great value. This is the new standard of value in high-performance bullet speakers.

Built to perform and able to handle 500 watts of continuous power, this midrange is the perfect option to replace those old 2-way or 3-way coaxial speakers. Engineered and designed to easily transform a stock system into one that can deliver concert levels. The 8MR500-4 BULLET is ideal for audiophiles seeking tremendous output without radical modifications.

Product Details

BrandPRV Audio
Model8MR500-4 BULLET
Part Number294-3143
UPC619620087638
Unit of MeasureEach
Weight5.55

Product Specifications

Nominal Diameter8"
Bolt Circle Diameter8
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance4Ω
Frequency Response95 to 20,000Hz
Sensitivity95dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)78.2Hz
DC Resistance (Re)3.5Ω
Voice Coil Inductance (Le)0.132mH
Mechanical Q (Qms)20.8
Electromagnetic Q (Qes)0.48
Total Q (Qts)0.46
Compliance Equivalent Volume (Vas)0.73ft³
Mechanical Compliance of Suspension (Cms)0.36mm/N
BL Product (BL)6.45T·m
Diaphragm Mass Inc. Airload (Mms)11.5g
Maximum Linear Excursion (Xmax)3.25mm
Surface Area of Cone (Sd)241cm²

Materials of Construction

Cone MaterialTreated Paper
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.27"
Baffle Cutout Diameter7.32"
Depth3.46"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.4ft³
Sealed F3134.7Hz
Vented Volume0.88ft³
Vented F370.4Hz
