PRV Audio 5MR450-NDY 5" Midrange Neodymium Woofer 8 Ohm

6 Questions, 17 Answers or
PRV Audio
Part #294-2705

PRV Audio 5MR450-NDY 5" Midrange Neodymium Woofer 8 Ohm

PRV Audio
Part #294-2705
Model: 5MR450-NDY
6 Questions, 17 Answers or
PRV Audio's 5MR450-NDY neodymium-powered midrange speaker features a sensitivity of 95 dB (2.83V/1m), weighs less than 3 pounds, and its 140 to 16,000 Hz frequency response allows it to be used for full range, single driver applications!
Key Features
  • Full copper sleeve on the pole-piece for low distortion and inductance
  • Low inductance for great transients and extended high frequency response
  • High EBP for horn-loaded enclosures
  • Naturally damped response for reduced top-octave ringing
  • Wide bandwidth that reaches out to 16 kHz and higher
Your Price: $99.91
+ FREE SHIPPING
MSRP: $124.89
Save $24.98 (20%)
Bulk Pricing
Ships next business day. Details

7In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

PRV Audio 5MR450-NDY 5" Midrange Neodymium Woofer 8 Ohm

The 5MR450-NDY, from PRV Audio, is built from the ground up to be a class-leading 5" midrange for pro audio, high output car audio, and high fidelity home audio applications. Its high-powered neodymium radial slugs immerse the voice coil in a strong magnetic field, providing extreme control and high senstivity. Additionally, the pole piece copper has a copper sleeve which lowers inductance thereby improving high frequency response.

Not only does the unique motor design keep the mounting depth at less than 3" (great for car doors), it also reduces distortion. With a usable, extended frequency response from 160 to 16,000 Hz, this midwoofer also works great as a high output, full range satellite speaker.

A bumped backplate, vented magnet assembly, vented pole piece, Kapton® former, open cast-aluminum frame, and treated-cloth surround allow for high power handling, while protecting this driver from extreme transient power peaks.

Product Details

BrandPRV Audio
Model5MR450-NDY
Part Number294-2705
UPC799928734349
Unit of MeasureEach
Weight2.9

Product Specifications

Nominal Diameter5"
Power Handling (RMS)225 Watts
Power Handling (MAX)450 Watts
Impedance
Frequency Response160 to 16,000Hz
Sensitivity94dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)159Hz
DC Resistance (Re)6.9Ω
Voice Coil Inductance (Le)0.03mH
Mechanical Q (Qms)22.26
Electromagnetic Q (Qes)0.66
Total Q (Qts)0.64
Compliance Equivalent Volume (Vas)0.05ft³
Mechanical Compliance of Suspension (Cms)0.116mm/N
BL Product (BL)9.42T·m
Diaphragm Mass Inc. Airload (Mms)8.6g
Maximum Linear Excursion (Xmax)3.45mm
Surface Area of Cone (Sd)95cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter5.18" across the flats, 5.79"
Baffle Cutout Diameter4.72"
Depth2.6"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.2ft³
Sealed F3196.8Hz
Vented Volume0.2ft³
Vented F3118.9Hz
