PRV Audio 15W1000v2 15" Professional Woofer 8 Ohm

PRV Audio
Part #294-2743

PRV Audio 15W1000v2 15" Professional Woofer 8 Ohm

PRV Audio
Part #294-2743
Model: 15W1000v2
The 15W1000v2 15" 8 ohm driver from PRV Audio features a water resistant cone making this woofer the ideal choice for high efficiency outdoor systems. The 3" high temperature voice coil has sufficient ventilation, thanks to the vented back plate, allowing continuous power handling of up to 500 watts.
Key Features
  • 97 dB sensitivity and 500 watt power handling for extreme output levels
  • 40 to 4,000 Hz response makes this driver suitable for two-way or three-way systems
  • Water resistant cone treatment for outdoor use
  • Large flat spider and multi-roll surround allow for 4.5 mm of excursion
Your Price: $89.91
MSRP: $112.39
Save $22.48 (20%)
Bulk Pricing
Order in the next 5 hr 39 min to ship today. Details

7In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 15W1000v2 15" Professional Woofer 8 Ohm

PRV Audio's 15W1000v2 15" professional 8 ohm woofer's reinforced paper cone has been treated to be water resistant making this the perfect driver for outdoor applications. With a vented pole piece and 3" voice coil this driver is capable of up to 500 watts of continuous power, and with 97 dB sensitivity that means exceptionally high output. The reinforced steel frame provides a sturdy support for long life in the difficult pro audio field.

Product Details

BrandPRV Audio
Model15W1000v2
Part Number294-2743
UPC799928734851
Unit of MeasureEach
Weight13.5

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.5
Power Handling (RMS)500 Watts
Power Handling (MAX)1000 Watts
Impedance8Ω
Frequency Response40 to 4,000Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)39.56Hz
DC Resistance (Re)5.5Ω
Voice Coil Inductance (Le)1.04mH
Mechanical Q (Qms)25.9
Electromagnetic Q (Qes)0.69
Total Q (Qts)0.68
Compliance Equivalent Volume (Vas)7.29ft³
Mechanical Compliance of Suspension (Cms)0.15mm/N
BL Product (BL)14.54T·m
Diaphragm Mass Inc. Airload (Mms)107.45g
Maximum Linear Excursion (Xmax)6.37mm
Surface Area of Cone (Sd)990cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.20"
Baffle Cutout Diameter13.90"
Depth5.82"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3ft³
Sealed F356.5Hz
Vented Volume4.25ft³
Vented F346.1Hz
