  • PRV Audio 15SW2000 15" Pro Audio Subwoofer 8 Ohm

PRV Audio 15SW2000 15" Pro Audio Subwoofer 8 Ohm

PRV Audio
Part #294-3007

PRV Audio 15SW2000 15" Pro Audio Subwoofer 8 Ohm

PRV Audio
Part #294-3007
Model: 15SW2000
The 15SW2000 is the first 15" pro audio subwoofer from PRV Audio. It offers the user an incredible punch to high power pro audio systems. The 15SW2000 loudspeaker has a very well-designed forced cooling system to ensure proper air ventilation for extended play.
Key Features
  • Impressive 96 dB sensitivity
  • Large 4" voice coil for high power handling
  • Forced air cooling system
  • Extremely linear 12.5 mm Xmax
Your Price: $189.91
+ FREE SHIPPING
MSRP: $237.39
Save $47.48 (20%)
Bulk Pricing
Order in the next 1 hr 28 min to ship today. Details

18In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 15SW2000 15" Pro Audio Subwoofer 8 Ohm

The 15SW2000 is the first 15" pro audio subwoofer from PRV Audio, It offers the user an incredible punch to high power pro audio systems. The 15SW2000 loudspeaker has a very well-designed forced cooling system to ensure proper air ventilation for extended play. The woven surround offers linear excursion along its impressive 12.5 mm XMAX.

The enhanced voice coil and cone material along with its ability to reproduce extremely low frequencies will ensure this is your subwoofer of choice from now on. The large 4" voice coil accepts the abuse of higher power systems while staying cool with the side forced air cooling system.

Product Details

BrandPRV Audio
Model15SW2000
Part Number294-3007
UPC602938022347
Unit of MeasureEach
Weight28.8

Product Specifications

Nominal Diameter15"
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Frequency Response45 to 2,300Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)52.9Hz
DC Resistance (Re)5.5Ω
Voice Coil Inductance (Le)1.51mH
Mechanical Q (Qms)16.54
Electromagnetic Q (Qes)0.57
Total Q (Qts)0.55
Compliance Equivalent Volume (Vas)2.17ft³
Mechanical Compliance of Suspension (Cms)0.05mm/N
BL Product (BL)23.19T·m
Diaphragm Mass Inc. Airload (Mms)169.1g
Maximum Linear Excursion (Xmax)12.5mm
Surface Area of Cone (Sd)908cm²

Materials of Construction

Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.47"
Baffle Cutout Diameter13.98"
Depth7.11"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2ft³
Sealed F376.6Hz
Vented Volume3.75ft³
Vented F344.1Hz
