  • Morel MW 1058 Classic Series 10" Paper / Carbon Fiber Cone Subwoofer

Morel MW 1058 Classic Series 10" Paper / Carbon Fiber Cone Subwoofer

Morel
Part #297-136

Morel MW 1058 Classic Series 10" Paper / Carbon Fiber Cone Subwoofer

Morel
Part #297-136
Model: MW 1058
With a huge 5.1" voice coil, double inside magnet assembly, and woven carbon fiber / paper laminate cone, Morel's MW1058 is a very powerful and unique subwoofer. Optimized for use in compact enclosures this high-end sub is suitable for both home and car audio designs.
Key Features
  • Massive 5.1" aluminum Hexatech voice coil handles extreme amounts of power
  • One of a kind stamped steel frame provides extensive venting for noise free operation
  • Rigid woven carbon fiber laminated paper cone for incredible damping
  • Huge spider and smooth transition surround keeps excursion as linear as possible
Your Price: $319.00
+ FREE SHIPPING
MSRP: $405.99
Save $86.99 (21%)
Bulk Pricing
Order in the next 5 hr 42 min to ship today. Details

Only 1 In Stock

More due any day
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Morel MW 1058 Classic Series 10" Paper / Carbon Fiber Cone Subwoofer

Morel's innovative engineering on the MW 1058 results in an extraordinary combination of audiophile quality bass and high power output for a great value. Featuring a gigantic 5.1” Hexatech external voice coil (hexagonal-shaped aluminum wire), the MW 1058 was created for accurate music reproduction, superior durability, and high power handling. A highly efficient double magnet ferrite motor maximizes the magnetic field to apply as much force to the coil as possible. The cone is a unique hybrid of carbon fiber composite laminated on paper to achieve an impressive mix of rigidity and damping for extraordinary musicality. Holding everything together is a solid stamped steel frame that provides extensive venting for the coil (under spider and pole piece venting) for minimal compression and quiet operation.

The MW 1058 is optimized to deliver powerful low frequencies when used in small enclosures. This driver is suitable for use in both hi-end home and car audio systems.

Product Details

BrandMorel
ModelMW 1058
Part Number297-136
UPC848864043678
Unit of MeasureEach
Weight16

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.96
Power Handling (RMS)500 Watts
Power Handling (MAX)1500 Watts
Impedance8Ω
Frequency Response30 to 900Hz
Sensitivity84.7dB 2.83V/1m
Voice Coil Diameter5.1"

Thiele-Small Parameters

Resonant Frequency (Fs)33Hz
DC Resistance (Re)5.9Ω
Voice Coil Inductance (Le)1.98mH
Mechanical Q (Qms)2.02
Electromagnetic Q (Qes)0.61
Total Q (Qts)0.47
Compliance Equivalent Volume (Vas)1.15ft³
Mechanical Compliance of Suspension (Cms)0.202mm/N
BL Product (BL)15.18T·m
Diaphragm Mass Inc. Airload (Mms)115.5g
Maximum Linear Excursion (Xmax)10mm
Surface Area of Cone (Sd)337.1cm²

Materials of Construction

Cone MaterialPaper / Carbon Fiber
Surround MaterialRubber
Voice Coil Wire MaterialAluminum
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.35"
Baffle Cutout Diameter8.86"
Depth5.38"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.62ft³
Sealed F355.7Hz
Vented Volume1.25ft³
Vented F331Hz
