  • Morel MDT 22 1-1/8" Soft Dome Neodymium Tweeter

Morel MDT 22 1-1/8" Soft Dome Neodymium Tweeter

Morel
Part #277-062

Morel MDT 22 1-1/8" Soft Dome Neodymium Tweeter

Morel
Part #277-062
Model: MDT 22
By adding a rear chamber to the MDT-12, a lower resonance point and superior low-frequency performance are achieved. The tweeter has a very rich and full sound, and can easily accommodate crossover points as low as 2k, making it work great with most woofers.
Key Features
  • Extremely low Fs allows crossover points as low as 2,000 Hz
  • Amazing performance for a tweeter this small
  • Smooth, detailed, and transparent response
  • Semi-horn loaded design improves effeciency
Your Price: $55.00
MSRP: $73.99
Save $18.99 (26%)
Bulk Pricing
Ships next business day. Details

Only 2 In Stock

More due any day

Free Shipping available on orders over $99.00 in the US. Details

Overview

Morel MDT 22 1-1/8" Soft Dome Neodymium Tweeter

By adding a rear chamber to the MDT-12, a lower resonance point and superior low-frequency performance are achieved. The tweeter has a very rich and full sound, and can easily accommodate crossover points as low as 2k, making it work great with most woofers. A large diameter 1-1/8" coil on aluminum former immersed in ferrofluid gives this unit good power handling.

Product Details

BrandMorel
ModelMDT 22
Part Number277-062
UPC844632019555
Unit of MeasureEach
Weight0.3

Product Specifications

Cone / Dome Diameter1.125"
Cutout Diameter1.75
Tweeter TypeSoft Dome
Power Handling (RMS)80 Watts
Impedance
Frequency Response1,800 to 25,000Hz
Sensitivity89dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)650Hz
DC Resistance (Re)5.2Ω

Mounting Information

Overall Outside Diameter2.13 x 2.13"
Depth2.38"
