  • LG 60881001 5/8" x 3-5/8" Paper Cone Dual Motor Full-Range Speaker

BUYOUT LG 60881001 5/8" x 3-5/8" Paper Cone Dual Motor Full-Range Speaker

Factory Buyouts
Part #289-2078

BUYOUT LG 60881001 5/8" x 3-5/8" Paper Cone Dual Motor Full-Range Speaker

Factory Buyouts
Part #289-2078
Model: EBZ60881001
LG's unique 60881001 5/8" x 3-5/8" dual motor full-range speaker, uses a single diaphragm with 2 separate coils. Originally used in a variety of LCD TVs from LG, this driver could be used in custom designs as well.
Key Features
  • Utilizes a unique design features 2 separate motors wired in series driving the same cone
  • Press fit design allows for a clean and simple installation
  • 8 Ohm impedance mates well to most small amplifiers
  • Rubber front gasket ensures good seal when rear mounted
BUYOUT $0.97
Bulk Pricing
Quantity:Qty: 1-9 $0.97/ea
Quantity:Qty: 10-99 $0.78/ea
Quantity:Qty: 100-499 $0.58/ea
Quantity:Qty: 500+$0.39/ea
Ships next business day. Details

12967In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

LG 60881001 5/8" x 3-5/8" Paper Cone Dual Motor Full-Range Speaker

We at Parts Express constantly hunt the globe for unique buyout opportunities so that we can provide our customers with the best products at the lowest cost. We are excited to offer this 5/8" x 3-5/8" speaker, which is part of a massive TV speaker factory buyout from Brazil.

Originally found in various high end LCD TVs from LG Electronics, this unique driver assembly consists uses two separate motors to drive a single cone. The extremely narrow assembly makes this a great choice for slim designs such as sound bars and portable speakers. With paper cones and voice coil formers with rubber surrounds these drivers will produce smooth response from 300 to 15,000 Hz..

Use these speakers in any low cost audio project whether it be a portable speaker, adding music to toys and models, or building an enormous line array for pennies. At such an economical price, these drivers won't last forever, quantities are limited.

Product Details

BrandFactory Buyouts
ModelEBZ60881001
Part Number289-2078
UPC848864047614
Unit of MeasureEach
Weight0.05

Product Specifications

Nominal Diameter1 x 5"
Power Handling (RMS)5 Watts
Power Handling (MAX)7 Watts
Impedance8Ω
Frequency Response480 to 15,000Hz
Sensitivity79.5dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)479.1Hz
DC Resistance (Re)7.11Ω
Voice Coil Inductance (Le)0.1332mH
Mechanical Q (Qms)4.92
Electromagnetic Q (Qes)9.23
Total Q (Qts)3.209

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialPolymer
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter0.87 x 4.03"
Baffle Cutout Diameter0.78 x 3.8"
Depth0.72"
