  • Goldwood GM-85/8 Heavy-Duty 5-1/4" Sealed Back Midrange 8 Ohm

Goldwood GM-85/8 Heavy-Duty 5-1/4" Sealed Back Midrange 8 Ohm

Goldwood
Part #280-115

Goldwood GM-85/8 Heavy-Duty 5-1/4" Sealed Back Midrange 8 Ohm

Goldwood
Part #280-115
Model: GM-85/8
Sealed back midrange eliminates need for separate midrange enclosure. Features poly-mica cone, treated foam surround, and aluminum voice coil for higher power handling.
Key Features
  • Cosmetic frame for a clean look without flush mounting
  • 1" aluminum voice coil improves power handling
  • Sealed back design eliminates the need for a sub-enclosure
  • Poly-mica cone with foam surround delivers accurate response
Similar items that may interest you:
Your Price: $14.98
MSRP: $20.99
Save $6.01 (29%)
Bulk Pricing
Quantity:Qty: 1-3 $14.98/ea
Quantity:Qty: 4-9 $14.23/ea
Quantity:Qty: 10+$13.48/ea
Ships next business day. Details

28In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Goldwood GM-85/8 Heavy-Duty 5-1/4" Sealed Back Midrange 8 Ohm

Sealed back midrange eliminates need for separate midrange enclosure. Features poly-mica cone, treated foam surround, and aluminum voice coil for higher power handling.

Product Details

BrandGoldwood
ModelGM-85/8
Part Number280-115
UPC643420300048
Unit of MeasureEach
Weight1.8

Product Specifications

Nominal Diameter5"
Power Handling (RMS)60 Watts
Power Handling (MAX)120 Watts
Impedance
Frequency Response500 to 15,000Hz
Sensitivity96dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)470Hz

Materials of Construction

Cone MaterialPoly
Surround MaterialFoam
Voice Coil Wire MaterialAluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter5.03125"
Baffle Cutout Diameter4.125"
Depth2.5"
# Mounting Holes4
