FaitalPRO 18XL1600 18" Neodymium Professional Subwoofer 8 Ohm

2 Questions or
FaitalPRO
Part #294-1313

FaitalPRO 18XL1600 18" Neodymium Professional Subwoofer 8 Ohm

FaitalPRO
Part #294-1313
Model: 18XL1600
2 Questions or
For a lightweight, high output 18" woofer with extended frequency response, choose FaitalPRO's neodymium-powered 18XL1600 subwoofer. Its 4" diameter voice coil offers up to 1,600 watts RMS power handling.
Key Features
  • 1,600 watt power handling and just 26.9 pounds
  • Low distortion motor with three aluminum shorting rings
  • Over 12 mm of Xmax for deep bass reproduction
  • Custom cast aluminum frame
  • Made in Italy
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $758.00
+ FREE SHIPPING
Bulk Pricing
Ships next business day. Details

Only 2 In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

FaitalPRO 18XL1600 18" Neodymium Professional Subwoofer 8 Ohm

FaitalPRO's 18XL1600 18" professional subwoofer packs 1,600 watts of RMS power handling into a package that weighs less than 27 pounds, thanks to a neodymium motor and 4" diameter voice coil on a glass fiber former. A cast aluminum eight-spoke frame reduces rear reflections and increases basket strength, while the triple roll treated polycotton surround maintains linearity during heavy excursion.

For an extended frequency response and reduced distortion, the 18XL1600 employs three separate aluminum demodulation rings within the motor to reduce inductance down to a low 1.45 mH. 12.9 mm of Xmax on tap allows you to use this woofer in vented cabinets that are tuned very low. Made in Italy.

Product Details

BrandFaitalPRO
Model18XL1600
Part Number294-1313
UPC848864008035
Unit of MeasureEach
Weight30.65

Product Specifications

Nominal Diameter18"
Bolt Circle Diameter17.32
Power Handling (RMS)1600 Watts
Power Handling (MAX)3200 Watts
Impedance8Ω
Frequency Response30 to 1,500Hz
Sensitivity98dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)32Hz
DC Resistance (Re)5.4Ω
Voice Coil Inductance (Le)1.45mH
Mechanical Q (Qms)9.3
Electromagnetic Q (Qes)0.37
Total Q (Qts)0.36
Compliance Equivalent Volume (Vas)6.52ft³
Mechanical Compliance of Suspension (Cms)0.1mm/N
BL Product (BL)26.7T·m
Diaphragm Mass Inc. Airload (Mms)240g
Maximum Linear Excursion (Xmax)12.9mm
Surface Area of Cone (Sd)1124cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter18.11"
Baffle Cutout Diameter16.54"
Depth9.09"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.5ft³
Sealed F371.1Hz
Vented Volume6ft³
Vented F333.9Hz
