Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm

Name: Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm
Brand: Eminence Speaker
SKU: 290-468
Price: 124.99 USD
Availability: InStock
Rating: 4.8 (5 reviews)

Read 5 Reviews | 5 Questions, 11 Answers or

Eminence Speaker

Part #290-468

Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm

Eminence Speaker

Part #290-468

Model: Legend B810

Read 5 Reviews | 5 Questions, 11 Answers or

The Legend B810 is a 32 ohm, 10" stamped frame bass guitar driver. A true classic design with some important updates.

See all items in Guitar Speakers & Bass Guitar Speakers

Your Price: $124.99

+ FREE SHIPPING

MSRP: $154.99

Bulk Pricing

Order in the next 2 hr 47 min to ship today. Details

Only 1 In Stock

More due any day

Get Notified When Available

We'll send you an email when Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm is back in stock or available for preorder.

Qty Quantity:

Free Shipping available on orders over $99.00 in the US. Details

60 Day No Hassle Return Policy

Frequently Bought Together

This Product: Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm	$124.99
Heavy Duty 10" Waffle Style Black Steel Speaker Grill with Rubber Edge	$7.49
Parts Express Cast Frame #10-32 Speaker Mounting Kit	$3.99
Parts Express Steel Bar Speaker Cabinet Handle	$6.29

Total Price: $142.76

This Product:Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm$124.99

Heavy Duty 10" Waffle Style Black Steel Speaker Grill with Rubber Edge$7.49

Parts Express Cast Frame #10-32 Speaker Mounting Kit$3.99

Parts Express Steel Bar Speaker Cabinet Handle$6.29

4 ItemsTotal Price: $142.76

Overview

Eminence Legend B810 10" Bass Guitar Driver 150W 32 Ohm

The Legend B810 is a 32 ohm, 10" stamped frame bass guitar driver. A true classic design with some important updates: an M-roll surround for higher excursion and less cone breakage, a double-dipped cone apex for an extra-strong cone neck, and a bumped back plate for greater voice coil travel before damage. Eminence's B810 offers classic sound with some modern features added to make a driver that will sound great and last a long time. Works well in small sealed enclosures and in some vented applications. The ultimate driver for classic 8 x 10" bass guitar cabinets. Use the Legend B810 four at a time, connected in parallel, to get an 8 ohm load. Eight of them connected in parallel will result in a 4 ohm load.

Specifications: • Power handling: 150 watts RMS/300 watts max • VCdia: 2" • Le: 2.72 mH • Impedance: 32 ohms • Re: 27.5 ohms • Frequency range: 49-5,100 Hz • Magnet weight: 30 oz. • Fs: 52.07 Hz • Sensitivity: 92.7 dB 1W/1m • Vas: 2.34 cu. ft. • Qms: 13.91 • Qes: 0.68 • Qts: 0.65 • Xmax: 4.7 mm • Dimensions: Overall diameter 10.11", Cutout diameter 9.13", Depth 4.08".

Product Details
Brand	Eminence Speaker
Model	Legend B810
Part Number	290-468
UPC	876358001705
Unit of Measure	Each
Weight	8

Product Specifications
Nominal Diameter	10"
Power Handling (RMS)	150 Watts
Impedance	32Ω

Materials of Construction
Magnet Material	Ceramic Ferrite
