Eminence Delta-15A 15" Driver 8 Ohm

Name: Eminence Delta-15A 15" Driver 8 Ohm
Brand: Eminence Speaker
SKU: 290-418
Price: 149.99 USD
Availability: InStock
Rating: 4.6 (16 reviews)

Read 16 Reviews | 15 Questions, 47 Answers or

Eminence Speaker

Part #290-418

Eminence Delta-15A 15" Driver 8 Ohm

Eminence Speaker

Part #290-418

Model: Delta-15A

Read 16 Reviews | 15 Questions, 47 Answers or

The Eminence Delta-15A 15" speaker is recommended for professional audio as a midbass or stage monitor woofer in sealed enclosures. Also suitable as a midbass or woofer in vented PA enclosures, as well as musical instrument systems.

Key Features

Kapton coil former
Polyamide-imide coated aluminum voice coil
Ferrite magnet
Vented pole piece
Pressed steel basket
Paper cone
Cloth accordian surround

Product Details

Brand

Eminence Speaker

Model

Delta-15A

Part Number

290-418

UPC

876358000258

Unit of Measure

Each

Weight

14.25

Product Specifications

Nominal Diameter

15"

Power Handling (RMS)

400 Watts

Power Handling (MAX)

800 Watts

Impedance

8Ω

Frequency Response

48 to 4,000Hz

Sensitivity

100dB 2.83V/1m

Voice Coil Diameter

2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)

40Hz

DC Resistance (Re)

6.3Ω

Voice Coil Inductance (Le)

0.64mH

Mechanical Q (Qms)

8.05

Electromagnetic Q (Qes)

0.57

Total Q (Qts)

0.53

Compliance Equivalent Volume (Vas)

9.56ft³

Mechanical Compliance of Suspension (Cms)

0.26mm/N

BL Product (BL)

13.2T·m

Diaphragm Mass Inc. Airload (Mms)

62g

Maximum Linear Excursion (Xmax)

2.7mm

Surface Area of Cone (Sd)

864.6cm²

Materials of Construction

Cone Material

Paper

Surround Material

Cloth

Voice Coil Wire Material

Aluminum

Voice Coil Former

Kapton® / Polyimide

Basket / Frame Material

Steel

Magnet Material

Ferrite

Mounting Information

Overall Outside Diameter

15.15"

Baffle Cutout Diameter

13.87"

Depth

6.05"

# Mounting Holes

Parts Express Staff Recommended Enclosure Volume

Sealed Volume

2.5ft³

Sealed F3

75Hz

Vented Volume

4.4ft³

Vented F3

53Hz
