Dayton Audio RS270-8 10" Reference Woofer

Dayton Audio
Part #295-357

Dayton Audio RS270-8 10" Reference Woofer

Dayton Audio
Part #295-357
Model: RS270-8
Dayton Audio Reference Series RS270-8 10" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.
Key Features
  • One of the lowest distortion, highest resolution driver series available
  • Low-distortion high-excursion motor system with two short-circuit paths
  • Compliant suspension and rigid black anodized aluminum cone for strong bass performance
  • Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
  • Designed and engineered in the USA
Your Price: $98.99
MSRP: $142.99
Save $44.00 (31%)
Bulk Pricing
Ships next business day. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio RS270-8 10" Reference Woofer

The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS270-8 10" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

Learn More
Request Quote

Product Details

BrandDayton Audio
ModelRS270-8
Part Number295-357
UPC844632088773
Unit of MeasureEach
Weight10.0008

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter10.16
Power Handling (RMS)100 Watts
Power Handling (MAX)200 Watts
Impedance8Ω
Frequency Response27 to 2,040Hz
Sensitivity88.7dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)29.6Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)0.93mH
Mechanical Q (Qms)2.08
Electromagnetic Q (Qes)0.61
Total Q (Qts)0.47
Compliance Equivalent Volume (Vas)3.4ft³
Mechanical Compliance of Suspension (Cms)0.57mm/N
BL Product (BL)10.3T·m
Diaphragm Mass Inc. Airload (Mms)50.5g
Maximum Linear Excursion (Xmax)6.6mm
Surface Area of Cone (Sd)346.4cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.71"
Baffle Cutout Diameter9.29"
Depth4.45"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1ft³
Sealed F358Hz
Vented Volume2.3ft³
Vented F334Hz
